Mitsubishi MUH-GA50VB User Manual

13
MUH-GA80VB
Unit:mm
Outdoor
heat
exchanger
Flared connection
Defrost
thermistor
RT61
Discharge
temperature
thermistor
RT62
Flared connection
Stop valve
Stop valve
(with service port)
Capillary tube
[3.6✕[2.4✕50
Refrigerant flow in cooling
Compressor
4-way valve
Refrigerant flow in heating
Refrigerant pipe [15.88
(with heat insulator)
Refrigerant pipe [9.52
(with heat insulator)
LEV
R.V. coil
heating ON
cooling OFF
Muffler
#100
Strainer
#100
Receiver
Muffler
Ambient
temperature
thermistor
RT63
Strainer
#100
MUH-GA60VB
Refrigerant pipe [15.88
(with heat insulator)
Flared connection
Flared connection
Refrigerant pipe [6.35
(with heat insulator)
Stop valve
Receiver
Check valve
Capillary tube
[3.0X[2.0X750
Defrost
thermistor
RT61
Compressor
Stop valve
(with service port)
Outdoor
heat
exchanger
Muffler
#100
4- way valve
[3.0X[2.0X750
Capillary tube
R.V. coil
Heating ON
Cooling OFF
Muffler
Strainer
#100
OB368B-1.qxp 10.5.25 9:14 AM Page 13

Mitsubishi MUH-GA50VB Specifications

General

Brand	Mitsubishi
Model	MUH-GA50VB
Category	Air Conditioner
Language	English
