Mitsubishi MUH-GA50VB User Manual

34
MUH-GA50VB
Outdoor deicer P.C. board
CN711
Outdoor fan motor
230V AC
CN721
R.V. coil
230V AC
F61
Fuse
2A/250V
}
}
CN661 1-2
Defrost thermistor RT61 (Refer to 10-4.F)
}
12V DC
J204
J101
R601
5~10V DC
}
--
+
5V DC
J205
J101
--
+
--
+
Power supply input
230V AC
}
NR61
Varistor
Jumper wire for
change in defrost
setting
(JRF,JRG)
(Refer to 9-2.)
}
Defrost interval time
short pin
(JPDS, JPSG)
(Refer to 9-1.)
(Refer to
10-4.A or
10-4.D.)
10-5. TEST POINT DIAGRAM AND VOLTAGE
OB368B-2.qxp 10.5.25 9:16 AM Page 34
