2. When replacing the bulb on the right side of
the vehicle in the case of diesel-powered ve-
hicles equipped with M/T, remove the bolts
(B) holding down the reservoir tank and
move the reservoir tank.
*: Front of the vehicle
3. Turn the socket (C) anticlockwise to remove
it.
*: Front of the vehicle
4. Remove the bulb from the socket.
5. To install the bulb, perform the removal
steps in reverse.
Front turn-signal lamps
E01003800977
1. When replacing the bulb on the right side of
the vehicle, remove the bolt (A) holding
down the washer tank spout and move the
spout towards the rear of the vehicle.
*: Front of the vehicle
2. Turn the socket (A) anticlockwise and re-
move it.
*: Front of the vehicle
3. Remove the bulb from the socket.
4. To install the bulb, perform the removal
steps in reverse.
Side turn-signal lamps (on fender)*
E01003900428
For the side turn-signal lamps (on fender), it is not
possible to repair or replace just the bulb.
Maintenance
8-29
