OC275-2
1
TECHNICAL CHANGE
PK18FL1 ➔ PK18FL3
PK24FL
1 ➔ PK24FL3
PK30FL
1 ➔ PK30FL3
PK36FL
1 ➔ PK36FL3
● REMOTE CONTROLLER has changed.
● INDOOR CONTROLLER BOARD has changed accordance with remote controller change.
1) From TRANSFORMER to POWER BOARD.
2) SW1 changed from function selector to mode selector.
3) SW2 changed from unit selector to address selector.
4) The number of switches of SW3 changed from 3 to 2 pieces.
5) Function of jumper wire for JR is blotted out and SW5 for model selector, SW6 for address selector, SW7 for model
selector, SW8 for option and SW9 for model selector are added.
OC275--1.qxp 01/12/14 3:06 PM Page 2
