Model name
Indoor unit PEAD-A24AA PEAD-A30AA PEAD-A36AA PEAD-A42AA
Outdoor unit
PUY-A24NHA3 PUY-A30NHA3 PUY-A36NHA3 PUY-A42NHA3
PUY-A24NHA3-BS PUY-A30NHA3-BS PUY-A36NHA3-BS PUY-A42NHA3-BS
Cooling
Max. Capacity Btu/h 24,000 30,000 35,000 42,000
Rated Capacity Btu/h 24,000 30,000 35,000 42,000
Min. Capacity Btu/h 12,000 12,000 12,000 18,000
Total Input W 2400 3850 4850 5350
EER Btu/h 10.0 7.7 7.2 7.8
SEER Btu/h 16.0 15.5 15.0 13.8
Moisture Removal Pints/h 6.9 8.6 7.9 9.0
SHF 0.68 0.68 0.75 0.76
Heating
Max. Capacity Btu/h - - - -
Rated Capacity Btu/h - - - -
Min. Capacity Btu/h - - - -
Total Input W - - - -
COP W/W - - - -
HSPF(IV/V) Btu/h/W - - - -
Heating
at low ambient
Rated Capacity Btu/h - - - -
Total Input W - - - -
COP W/W - - - -
Power supply
Phase,Cycle,Voltage 1phase, 60Hz, 208/230V
Breaker size A 25 30
Voltage
Indoor - Outdoor S1-S2 AC208 / 230V
Indoor - Outdoor S2-S3 DC24V
Indoor - Remote controller DC12V
Indoor unit
MCA A 2.63 2.73 3.30 3.50
MOCP A 15 15 15 15
Fan Motor F.L.A 2.10 2.18 2.64 2.80
Fan Motor Output W 121 244
Air fl ow DRY
(Lo-Mid-Hi) WET
CMM 14.5-18-21 17.5-21-25 24-29-34 29.5-35.5-42
CMM 14-17-19 16-19-23 22-27-32 27-33-40
Air fl ow DRY
(Lo-Mid-Hi) WET
CFM 512-636-742 618-742-883 847-1024-1201 1042-1254-1483
CFM 494-600-671 565-671-812 777-953-1130 953-1165-1412
External pressure in.WG [Pa] [35/50/70/100/150]
Sound level
(Lo-Mid-Hi)
dB(A)
30-33-37 30-34-39 33-38-42 36-40-44
External fi nish Galvanized
Dimension
Unit (Panel)
W:mm[inch] 1100[43-5/16] 1400[55-1/8]
D:mm[inch] 732[28-7/8]
H:mm[inch] 250[9-7/8]
Weight kg 33 41 43
Unit lbs 73 91 95
Field Drain pipe seize O.D.
mm[inch] 32 [1-1/4]
Remote Controller
Attached in indoor Unit
Outdoor unit
MCA A 18 25 26
MOCP A 30 40
Fan Motor F.L.A. 0.75 0.4+0.4
Fan Motor Output W 75 86+86
Compressor TNB220FLHM ANV33FDPMT
R.L.A. 12 20
L.R.A. 14 17.5 27.5
Air fl ow CMM[CFM] 55 [1,940] 100[3,530]
Refrigerant Control Linear Expansion Valve
Defrost Method -
Sound level at cooling dB(A) 48 51
Sound level at heating dB(A) -
External fi nish Ivory Munsell 3Y 7.8/1.1
Dimension
W:mm[inch] 950 [37-3/8]
D:mm[inch] 330+30 [13+1-3/16] 1350[53-1/8]
H:mm[inch] 943 [37-1/8] 118[260]
Weignt
kg[lbs]
75[165] 118[260]
Refrigerant
Type R410A
Charge kg[lbs,oz] 3.0 [6 lbs 10oz] 4.5 [10lbs]
Oil L[oz] 0.87 (FV50S) [28] 1.4 (FV50S) [45]
Refrigerant pipe size
Gas side O.D. mm[inch] 15.88[5/8]
Liquid side O.D. mm[inch] 9.52[3/8]
Refrigerant pipe length
Height difference Max. 30m [Max.100ft]
Length Max. 50m [Max.165ft]
Refrigerant Piping
Not Supplied
Connection Method
Flared
NOTES : *1.Rating conditions (cooling)-Indoor : D.B. 26.7:(80°F), W.B. 19.4:(67°F) Outdoor : D.B. 35:(95°F), W.B. 23.9:(75°F)
(heating)-Indoor : D.B. 21.1:(70°F), W.B. 15.6:(60°F) Outdoor : D.B. 8.3:(47°F), W.B. 6.1:(43°F)
*2.Rating conditions(heating)-Indoor : D.B. 21.1:(70°F), W.B. 15.6:(60°F) Outdoor : D.B. -8.3:(17°F), W.B. -9.4:(15°F)
Operating range
Indoor intake air temperature
D.B. 35:(95°F), W.B. 21.7:(71°F)
D.B. 19.4:(67°F), W.B. 13.9:(57°F)
D.B. 26.7:(80°F), W.B. 19.4:(67°F)
D.B. 21.1:(70°F), W.B. 15.6:(60°F)
Outdoor intake air temperature
D.B. 46:(115°F)
D.B. -18:(0°F)*
D.B. 21.1:(70°F), W.B. 15:(59°F)
D.B. -11.1:(12°F), W.B. -12.2:(10°F)
Cooling
Heating
Maximum
Minimum
Maximum
Minimum
* In case that the wind baffle is installed. (In case that the wind baffle is not installed, the minimum temperature will be -5:(23°F)DB.)
