10-1. OUTLET AIR SPEED AND COVERAGE RANGE
CFM
ft/sec.(m/sec.)
ft(m)
Air flow
Air speed
Coverage range
CFM
ft/sec.(m/sec.)
ft(m)
Air flow
Air speed
Coverage range
CFM
ft/sec.(m/sec.)
ft(m)
Air flow
Air speed
Coverage range
CFM
ft/sec.(m/sec.)
ft(m)
PLA-A30BA PLA-A36BA PLA-A42BA
1060
17.4(5.3)
26(8.0)
1090
17.7(5.4)
26(8.2)
Air flow
Air speed
Coverage range
740
12.1(3.7)
18(5.6)
530
8.5(2.6)
13(4.1)
640
10.5(3.2)
15(4.8)
640
10.5(3.2)
15(4.8)
PLA-A12BA PLA-A18BA
PLA-A24BA
PCA-A24KA
PCA-A30KA
PCA-A36KA
PCA-A42KA
990
11.8(3.6)
41(12.5)
705
10.5(3.2)
33(10.1)
670
10.2(3.1)
32(9.6)
1025
12.1(3.7)
42(12.9)
425
20.0(6.1)
35(10.8)
PKA-A12HAL
PKA-A12HA
PKA-A18HAL
PKA-A18HA
425
20.0(6.1)
35(10.8)
775
19.7(6.0)
47(14.3)
775
19.7(6.0)
47(14.3)
PKA-A24KAL
PKA-A24KA
PKA-A30KAL
PKA-A30KA
PKA-A36KAL
PKA-A36KA
920
22.3(6.8)
53(16.1)
The air coverage range is the distance to which the 0.8 ft/sec. air can reach, when air is blown out horizontally from the unit at
the High notch position.
The coverage range should be used only as a general guideline since it varies according to the size of the room and the furni-
ture inside the room.
