Model name Indoor unit
PLA-A36BA PKA-A36KA(L)
Outdoor unit
PUZ-HA36NHA2 PUZ-HA36NHA2
Cooling Max. Capacity Btu/h
34,200
Rated Capacity Btu/h
33,500
Min. Capacity Btu/h
36,000
34,000
18,000
2,690
12.6
17.0
7.1
0.71
18,000
2,790
12.0
16.2
8.7
0.71
Total Input W
EER Btu/h/W
SEER Btu/h/W
Moisture Removal Pints/h
*1 SHF
Heating Max. Capacity Btu/h
40,000 40,000
Rated Capacity Btu/h
38,000 38,000
Min. Capacity Btu/h
18,000 18,000
3,410
3.27
10.0 / 7.8
Total Input W
3,230
COP W/W 3.45
10.0 / 8.0
*1 HSPF(IV/V) Btu/h/W
Heating at 17°F(-8.3°C) Max.Capacity Btu/h
38,000 38,000
Total Input W
5,300 6,010
*2 COP W/W
2.10 1.85
Heating at 5°F(-15°C) Max. Capacity Btu/h
38,000 38,000
6,760
1.65
Total Input W
5,860
*3 COP W/W
1.90
PLA-A30BA
PUZ-HA30NHA2
30,000
30,000
18,000
2,450
12.2
15.6
7.2
0.73
34,000
32,000
18,000
3,440
2.73
9.4 / 7.1
32,000
5,720
1.64
32,000
6,630
1.41
PKA-A30KA(L)
PUZ-HA30NHA2
30,000
30,000
18,000
2,500
12.0
16.5
8.1
0.70
34,000
32,000
18,000
2,930
3.20
9.5 / 7.3
32,000
5,080
1.85
32,000
5,770
1.63
Power supply Phase, Cycle, Voltage
1phase, 60Hz, 208/230V 1phase, 60Hz, 208/230V
Breaker size A
30 30
Voltage Indoor - Outdoor S1 - S2
AC208/230V
AC208/230V
Indoor - Outdoor S2 - S3
DC24V DC24V
Indoor - Remote Controller
DC12V DC12V : Wired type
Indoor unit MCA A
21
MOCP A
15 15
Fan Motor F.L.A. 1.00 0.57
Fan Motor Output W
120
Airflow DRY CMM
20-23-26-30 20-23-26
Airflow WET CMM
19-22-25-29 18-21-23
Airflow DRY CFM
710-810-920-1060 705-810-920
Airflow WET CFM
670-770-880-1030
1
0.51
50
14-16-18-21
13-15-17-20
490-570-640-740
460-530-600-710 635-730-830
External pressure Pa 00
Sound level dB(A)
32-34-37-4028-30-32-34 43-46-49
0.36
56
18-20-22
16-18-20
635-705-775
570-635-700
39-42-45
External finish (Grille)
White Munsell 6.4Y 8.9/0.4 White Munsell 1.0Y 9.2/0.2
Dimension Unit (Grille) W : mm[inch]
840(950) [33-1/16(37-3/8)] 1170 [46-1/16]
D : mm[inch]
840(950) [33-1/16(37-3/8)] 295 [11-5/8]
H : mm[inch]
298(35) [11-3/4(1-3/8)]
365 [14-3/8]
Weight Unit(Grille) kg
25(6)
258(35) [10-3/16(1-3/8)]
23(6)
Weight Unit(Grille) lbs
55(13)
21
46
Field drain pipe size mm[inch]
O.D. 32 [1-1/4] I.D. 16 [5/8]
Remote Controller
Attached in Grille Attached in Indoor unit
Outdoor unit MCA A
28
MOCP A
40
Fan Motor F.L.A.
0.4 + 0.4
Fan Motor Output W
60 + 60
Compressor Type
ANB33FJEMTANB33FJEMT ANB33FJEMT
R.L.A. 18
L.R.A.
27.5
Air flow CMM[CFM]
100[3,530]
Refrigerant Control
Electronic Expansion Valve
Defrost Method
Reverse Cycle
Sound level at cooling dB(A)
52
Sound level at heating dB(A)
53
External finish
Ivory Munsell 3Y 7.8/1.1
Dimension W : mm[inch]
950 [37-3/8]
D : mm[inch]
330 + 30 [13 + 1-3/16]
H : mm[inch] 1,350 [53-1/8]
Weight kg[lbs]
120 [265]
Refrigerant Type
R410A
Charge kg[lbs, oz]
5.5 [12 lbs]
Oil L[oz]
1.4(FV50S) [45]
Refrigerant pipe size Gas side O.D. mm[inch]
15.88 [5/8]
Liquid side O.D. mm[inch]
9.52 [3/8]
Refrigerant pipe length Height difference
Max.30m [Max.100ft]
Length
Max.75m [Max.245ft]
Refrigerant Piping
Not Supplied
Connection Method
Flared
28
40
0.4 + 0.4
60 + 60
ANB33FJEMT
18
27.5
100[3,530]
Electronic Expansion Valve
Reverse Cycle
52
53
Ivory Munsell 3Y 7.8/1.1
950 [37-3/8]
330 + 30 [13 + 1-3/16]
1,350 [53-1/8]
120 [265]
R410A
5.5 [12 lbs]
1.4(FV50S) [45]
15.88 [5/8]
9.52 [3/8]
Max.30m [Max.100ft]
Max.75m [Max.245ft]
Not Supplied
Flared
51(13)
NOTES : *1.Rating conditions (cooling)-Indoor : D.B. 26.7°C(80°F), W.B. 19.4°C(67°F) Outdoor : D.B. 35°C(95°F), W.B. 23.9°C(75°F)
(heating)-Indoor : D.B. 21.1°C(70°F), W.B. 15.6°C(60°F) Outdoor : D.B. 8.3°C(47°F), W.B. 6.1°C(43°F)
*2.Conditions (heating)-Indoor : D.B. 21.1°C(70°F), W.B. 15.6°C(60°F) Outdoor : D.B. -8.3°C(17°F), W.B. -9.4°C(15°F)
*3.Conditions (heating)-Indoor : D.B. 21.1°C(70°F), W.B. 15.6°C(60°F) Outdoor : D.B. -15°C(5°F), W.B. -15°C(5°F)
Operating range
Indoor intake air temperature
D.B. 32°C(90°F), W.B. 23°C(73°F)
D.B. 19°C(66°F), W.B. 15°C(59°F)
D.B. 28°C(83°F)
D.B. 17°C(63°F)
Outdoor intake air temperature
D.B. 46°C(115°F)
D.B. -18°C(0°F)*
D.B. 21.1°C(70°F), W.B. 15°C(59°F)
D.B. -25°C(-13°F), W.B. -25°C(-13°F)
Cooling
Heating
Maximum
Minimum
Maximum
Minimum
* In case that the wind baffle is installed. (In case that the wind baffle is not installed, the minimum temperature will be -5°C(23°F)DB.)
