NOTES : *1.Rating conditions (cooling)-Indoor : D.B. 26.7°C(80°F), W.B. 19.4°C(67°F) Outdoor : D.B. 35°C(95°F), W.B. 23.9°C(75°F)
(heating)-Indoor : D.B. 21.1°C(70°F), W.B. 15.6°C(60°F) Outdoor : D.B. 8.3°C(47°F), W.B. 6.1°C(43°F)
*2.Conditions (heating)-Indoor : D.B. 21.1°C(70°F), W.B. 15.6°C(60°F) Outdoor : D.B. -8.3°C(17°F), W.B. -9.4°C(15°F)
*3.Conditions (heating)-Indoor : D.B. 21.1°C(70°F), W.B. 15.6°C(60°F) Outdoor : D.B. -15°C(5°F), W.B. -15°C(5°F)
Operating range
Indoor intake air temperature
D.B. 32°C(90°F), W.B. 23°C(73°F)
D.B. 19°C(66°F), W.B. 15°C(59°F)
D.B. 28°C(83°F)
D.B. 17°C(63°F)
Outdoor intake air temperature
D.B. 46°C(115°F)
D.B. -18°C(0°F)*
D.B. 21.1°C(70°F), W.B. 15°C(59°F)
D.B. -25°C(-13°F), W.B. -25°C(-13°F)
Cooling
Heating
Maximum
Minimum
Maximum
Minimum
* In case that the wind baffle is installed. (In case that the wind baffle is not installed, the minimum temperature will be -5°C(23°F)DB.)
Model name Indoor unit
Outdoor unit
Cooling Max. Capacity Btu/h
Rated Capacity Btu/h
Min. Capacity Btu/h
Total Input W
EER Btu/h/W
SEER Btu/h/W
Moisture Removal Pints/h
*1 SHF
Heating Max. Capacity Btu/h
Rated Capacity Btu/h
Min. Capacity Btu/h
Total Input W
COP W/W
*1 HSPF(IV/V) Btu/h/W
Heating at 17°F(-8.3°C) Max. Capacity Btu/h
Total Input W
*2 COP W/W
Heating at 5°F(-15°C) Max. Capacity Btu/h
Total Input W
*3 COP W/W
PEA-A18AA×2
PUZ-HA36NHA2
36,000
34,000
18,000
2700
12.5
16.8
6.7
0.78
40,000
38,000
18,000
3150
3.53
10.4/8.2
38,000
5400
2.06
38,000
6100
1.82
PEAD-A30AA
PUZ-HA30NHA2
30,000
30,000
18,000
2500
12.0
16.5
8.9
0.67
34,000
32,000
18,000
2750
3.41
9.5/7.3
32,000
4930
1.90
32,000
5420
1.73
PEAD-A36AA
PUZ-HA36NHA2
36,000
34,000
18,000
2800
12.1
16.8
7.3
0.76
40,000
38,000
18,000
3150
3.53
10.4/8.2
38,000
5400
2.06
38,000
6100
1.82
Power supply Phase, Cycle, Voltage
1phase, 60Hz, 208/230V
Breaker size A
30
Voltage Indoor - Outdoor S1 - S2
AC208/230V
Indoor - Outdoor S2 - S3
DC24V
Indoor - Remote Controller
DC12V
Indoor unit MCA A
MOCP A
Fan Motor F.L.A.
Fan Motor Output W
Airflow DRY (Lo-Mid-Hi) CMM
Airflow WET (Lo-Mid-Hi) CMM
Airflow DRY (Lo-Mid-Hi) CFM
Airflow WET (Lo-Mid-Hi) CFM
2
15
0.74
96
12-15-18
11-14-17
423-529-635
381-476-572
[5/15/35/50]
30-34-38
1190[46-7/8]
700[27-9/16]
200[7-7/8]
27
60
2.73
15
2.18
0.121
17.5-21-25
16-19-23
618-742-883
565-671-812
30-34-39
Galvanized
1100[43-5/16]
33
73
[35/50/70/100/150]
732[28-7/8]
250[9-7/8]
15.88 [5/8] / 12.7[1/2]
9.52 [3/8] / 6.35[1/4]
15.88 [5/8]
9.52 [3/8]
3.30
15
2.64
0.244
24-29-34
22-27-32
847-1024-1201
777-953-1130
33-38-42
1400[5-1/8]
41
91
External pressure Pa
Sound level (Lo-Mid-Hi) dB(A)
External finish
Dimension Unit (Panel) W : mm[inch]
D : mm[inch]
H : mm[inch]
Weight Unit
kg
lbs
Field drain pipe size mm[inch]
32 [1-1/4]
Remote Controller
Attached in indoor Unit
Outdoor unit MCA A
28
MOCP A
40
Fan Motor F.L.A.
0.4 + 0.4
Fan Motor Output W
60 + 60
Compressor Type
ANB33FJEMT
R.L.A.
18
L.R.A.
27.5
Air flow CMM[CFM]
100[3,530]
Refrigerant Control
Electronic Expansion Valve
Defrost Method Reverse Cycle
Sound level at cooling dB(A)
52
Sound level at heating dB(A)
53
External finish Ivory Munsell 3Y 7.8/1.1
Dimension W : mm[inch]
950 [37-3/8]
D : mm[inch]
330+30 [13 + 1-3/16]
H : mm[inch]
1,350 [53-1/8]
Weight kg[lbs]
120 [265]
Refrigerant Type
R410A
Charge kg[lbs, oz]
5.5 [12 lbs]
Oil L[oz]
1.4(FV50S) [45]
Refrigerant pipe size Gas side O.D. mm[inch]
Liquid side O.D. mm[inch]
Refrigerant pipe length Height difference
Max.30m [Max.100ft]
Length
Max.75m [Max. 245ft]
Refrigerant Piping Not Supplied
Connection Method
Flared
To Next Page
