Mitsubishi PLA-A12BA

48
Rated heating performance curve
Rated heating capacity
0.50
1.00
1.50
2.00
80˚F (27˚C)
70˚F (21˚C)
60˚F (16˚C)
60˚F (16˚C)
70˚F (21˚C)
80˚F (27˚C)
Outdoor ambient temp.
INPUT (RATIO) CAPACITY (RATIO)
0.60
0.80
1.00
1.20
1.40
-15 -10 -5 0 5 10 15 20 25 30 35 40 45 50 55 60
-26 -23 -21 -18 -15 -12 -9 -7 -4 -1 2 4 7 10 13 16
Outdoor ambient temp.
-15 -10 -5 0 5 10 15 20 25 30 35 40 45 50 55 60
-26 -23 -21 -18 -15 -12 -9 -7 -4 -1 2 4 7 10 13 16
(˚FWB)
(˚CWB)
(˚FWB)
(˚CWB)
Heating input
Indoor intake air dry-bulb temperature (˚F DB)
Indoor intake air dry-bulb temperature (˚F DB)
