8-1-2. HEATING CAPACITY
PUZ-A·NHA3
Model Name
Capacity
Btu/h
Input
kW
Indoor
intake air
D.B.(°C)
Indoor
intake air
D.B.(°F)
Outdoor intake air °C/°F W.B.
-10/14 -5/23 0/32 5/41 10/50 15/59
CA P.C. CA P.C. CA P.C. CA P.C. CA P.C. CA P.C.
PLA-A18BA 19,000 1.9
15 59 12,350 1.13 13,300 1.25 14,630 1.47 19,190 1.72 21,660 1.94 23,940 2.08
20 68 11,970 1.23 12,730 1.35 13,870 1.56 18,430 1.86 20,900 2.05 23,180 2.23
25 77 11,400 1.31 12,160 1.47 13,300 1.71 17,480 1.97 20,140 2.23 22,420 2.38
PLA-A24BA 26,000 2.57
15 59 16,900 1.52 18,200 1.70 20,020 1.98 26,260 2.33 29,640 2.62 32,760 2.81
20 68 16,380 1.67 17,420 1.82 18,980 2.11 25,220 2.52 28,600 2.78 31,720 3.01
25 77 15,600 1.78 16,640 1.98 18,200 2.32 23,920 2.67 27,560 3.01 30,680 3.22
PLA-A30BA 32,000 3.37
15 59 20,800 2.00 22,400 2.23 24,640 2.60 32,320 3.06 36,480 3.43 40,320 3.68
20 68 20,160 2.18 21,440 2.39 23,360 2.77 31,040 3.31 35,200 3.64 39,040 3.95
25 77 19,200 2.33 20,480 2.60 22,400 3.04 29,440 3.49 33,920 3.95 37,760 4.22
PLA-A36BA 37,000 3.3
15 59 24,050 1.96 25,900 2.18 28,490 2.55 37,370 2.99 42,180 3.36 46,620 3.61
20 68 23,310 2.14 24,790 2.34 27,010 2.71 35,890 3.24 40,700 3.56 45,140 3.87
25 77 22,200 2.28 23,680 2.55 25,900 2.97 34,040 3.42 39,220 3.87 43,660 4.14
PLA-A42BA 45,000 4.45
15 59 29,250 2.64 31,500 2.94 34,650 3.43 45,450 4.04 51,300 4.53 56,700 4.86
20 68 28,350 2.88 30,150 3.16 32,850 3.65 43,650 4.37 49,500 4.81 54,900 5.22
25 77 27,000 3.08 28,800 3.43 31,500 4.01 41,400 4.61 47,700 5.22 53,100 5.58
Model Name
Capacity
Btu/h
Input
kW
Indoor
intake air
D.B.(°C)
Indoor
intake air
D.B.(°F)
Outdoor intake air °C/°F W.B.
-10/14 -5/23 0/32 5/41 10/50 15/59
CA P.C. CA P.C. CA P.C. CA P.C. CA P.C. CA P.C.
PKA-A18HA 19,000 1.97
15 59 12,350 1.17 13,300 1.30 14,630 1.52 19,190 1.79 21,660 2.01 23,940 2.15
20 68 11,970 1.28 12,730 1.40 13,870 1.62 18,430 1.93 20,900 2.13 23,180 2.31
25 77 11,400 1.36 12,160 1.52 13,300 1.78 17,480 2.04 20,140 2.31 22,420 2.47
PKA-A24KA 26,000 2.33
15 59 16,900 1.38 18,200 1.54 20,020 1.80 26,260 2.11 29,640 2.37 32,760 2.55
20 68 16,380 1.51 17,420 1.65 18,980 1.91 25,220 2.29 28,600 2.52 31,720 2.73
25 77 15,600 1.61 16,640 1.80 18,200 2.10 23,920 2.42 27,560 2.73 30,680 2.92
PKA-A30KA 32,000 3.15
15 59 20,800 1.87 22,400 2.08 24,640 2.43 32,320 2.86 36,480 3.21 40,320 3.44
20 68 20,160 2.04 21,440 2.24 23,360 2.59 31,040 3.09 35,200 3.40 39,040 3.69
25 77 19,200 2.18 20,480 2.43 22,400 2.84 29,440 3.27 33,920 3.69 37,760 3.95
PKA-A36KA 37,000 3.61
15 59 24,050 2.14 25,900 2.38 28,490 2.79 37,370 3.28 42,180 3.68 46,620 3.94
20 68 23,310 2.34 24,790 2.56 27,010 2.96 35,890 3.54 40,700 3.90 45,140 4.23
25 77 22,200 2.50 23,680 2.79 25,900 3.25 34,040 3.74 39,220 4.23 43,660 4.52
Model Name
Capacity
Btu/h
Input
kW
Indoor
intake air
D.B.(°C)
Indoor
intake air
D.B.(°F)
Outdoor intake air °C/°F W.B.
-10/14 -5/23 0/32 5/41 10/50 15/59
CA P.C. CA P.C. CA P.C. CA P.C. CA P.C. CA P.C.
PCA-A24KA 26,000 2.31
15 59 16,900 1.37 18,200 1.53 20,020 1.78 26,260 2.10 29,640 2.35 32,760 2.52
20 68 16,380 1.50 17,420 1.64 18,980 1.90 25,220 2.27 28,600 2.50 31,720 2.71
25 77 15,600 1.60 16,640 1.78 18,200 2.08 23,920 2.40 27,560 2.71 30,680 2.89
PCA-A30KA 32,000 3.21
15 59 20,800 1.90 22,400 2.12 24,640 2.48 32,320 2.91 36,480 3.27 40,320 3.51
20 68 20,160 2.08 21,440 2.28 23,360 2.64 31,040 3.15 35,200 3.47 39,040 3.76
25 77 19,200 2.22 20,480 2.48 22,400 2.89 29,440 3.33 33,920 3.76 37,760 4.02
PCA-A36KA 37,000 3.19
15 59 24,050 1.89 25,900 2.11 28,490 2.46 37,370 2.89 42,180 3.25 46,620 3.49
20 68 23,310 2.07 24,790 2.26 27,010 2.62 35,890 3.13 40,700 3.45 45,140 3.74
25 77 22,200 2.21 23,680 2.46 25,900 2.87 34,040 3.31 39,220 3.74 43,660 4.00
PCA-A42KA 45,000 3.83
15 59 29,250 2.27 31,500 2.53 34,650 2.96 45,450 3.48 51,300 3.90 56,700 4.18
20 68 28,350 2.48 30,150 2.72 32,850 3.14 43,650 3.76 49,500 4.14 54,900 4.49
25 77 27,000 2.65 28,800 2.96 31,500 3.45 41,400 3.97 47,700 4.49 53,100 4.80
Model Name
Capacity
Btu/h
Input
kW
Indoor
intake air
D.B.(°C)
Indoor
intake air
D.B.(°F)
Outdoor intake air °C/°F W.B.
-10/14 -5/23 0/32 5/41 10/50 15/59
CA P.C. CA P.C. CA P.C. CA P.C. CA P.C. CA P.C.
PEAD-A24AA 26,000 2.25
15 59 16,900 1.33 18,200 1.49 20,020 1.74 26,260 2.04 29,640 2.29 32,760 2.46
20 68 16,380 1.46 17,420 1.60 18,980 1.85 25,220 2.21 28,600 2.43 31,720 2.64
25 77 15,600 1.56 16,640 1.74 18,200 2.03 23,920 2.33 27,560 2.64 30,680 2.82
PEAD-A30AA 32,000 2.99
15 59 20,800 1.77 22,400 1.97 24,640 2.31 32,320 2.71 36,480 3.05 40,320 3.27
20 68 20,160 1.94 21,440 2.12 23,360 2.45 31,040 2.93 35,200 3.23 39,040 3.51
25 77 19,200 2.07 20,480 2.31 22,400 2.69 29,440 3.10 33,920 3.51 37,760 3.75
PEAD-A36AA 37,000 3.29
15 59 24,050 1.95 25,900 2.17 28,490 2.54 37,370 2.99 42,180 3.35 46,620 3.59
20 68 23,310 2.13 24,790 2.34 27,010 2.70 35,890 3.23 40,700 3.55 45,140 3.86
25 77 22,200 2.27 23,680 2.54 25,900 2.97 34,040 3.41 39,220 3.86 43,660 4.12
PEAD-A42AA 45,000 3.82
15 59 29,250 2.26 31,500 2.52 34,650 2.95 45,450 3.47 51,300 3.89 56,700 4.17
20 68 28,350 2.48 30,150 2.71 32,850 3.14 43,650 3.75 49,500 4.13 54,900 4.48
25 77 27,000 2.64 28,800 2.95 31,500 3.44 41,400 3.96 47,700 4.48 53,100 4.79
Model Name
Capacity
Btu/h
Input
kW
Indoor
intake air
D.B.(°C)
Indoor
intake air
D.B.(°F)
Outdoor intake air °C/°F W.B.
-10/14 -5/23 0/32 5/41 10/50 15/59
CA P.C. CA P.C. CA P.C. CA P.C. CA P.C. CA P.C.
PEA-A18AA.TH 19,000 1.54
15 59 12,350 0.91 13,300 1.02 14,630 1.19 19,190 1.40 21,660 1.57 23,940 1.68
20 68 11,970 1.00 12,730 1.09 13,870 1.26 18,430 1.51 20,900 1.66 23,180 1.81
25 77 11,400 1.06 12,160 1.19 13,300 1.39 17,480 1.60 20,140 1.81 22,420 1.93
Note: CA : Capacity (Btu/h) P.C. : Power consumption (kW)
D.B. : Dry-bulb temperature W.B. : Wet-bulb temperature
