Mitsubishi PLA-A12BA

66
8-2-2. HEATING CAPACITY
Model Name
Capacity
Btu/h
Input
kW
Indoor
intake air
D.B.(°C)
Indoor
intake air
D.B.(°F)
Outdoor intake air °C/°F W.B.
-25/-13 -20/-4 -15/5 -10/14 -5/23 0/32 5/41 10/50 15/59
CA P.C. CA P.C. CA P.C. CA P.C. CA P.C. CA P.C. CA P.C. CA P.C. CA P.C.
PLA-A30BA 32,000 3.44
16 60 26,880 6.36 30,080 6.31 33,280 6.26 33,280 5.88 33,280 5.40 33,280 4.41 33,280 3.33 36,480 3.66 40,320 3.89
21 70 25,600 6.58 28,800 6.52 32,000 6.47 32,000 6.10 32,000 5.61 32,000 4.62 32,000 3.62 35,200 3.87 38,880 4.18
27 80 24,320 6.79 27,520 6.74 30,720 6.68 30,720 6.31 30,720 5.83 30,720 4.84 30,720 3.87 33,920 4.16 37,600 4.52
PLA-A36BA 38,000 3.23
16 60 31,920 5.97 35,720 5.92 39,520 5.87 39,520 5.52 39,520 5.07 39,520 4.14 39,520 3.13 43,320 3.43 47,880 3.65
21 70 30,400 6.17 34,200 6.12 38,000 6.07 38,000 5.72 38,000 5.27 38,000 4.34 38,000 3.40 41,800 3.63 46,170 3.92
27 80 28,880 6.38 32,680 6.33 36,480 6.28 36,480 5.92 36,480 5.47 36,480 4.54 36,480 3.63 40,280 3.90 44,650 4.24
Model Name
Capacity
Btu/h
Input
kW
Indoor
intake air
D.B.(°C)
Indoor
intake air
D.B.(°F)
Outdoor intake air °C/°F W.B.
-25/-13 -20/-4 -15/5 -10/14 -5/23 0/32 5/41 10/50 15/59
CA P.C. CA P.C. CA P.C. CA P.C. CA P.C. CA P.C. CA P.C. CA P.C. CA P.C.
PKA-A30KA 32,000 2.93
16 60 26,880 5.42 30,080 5.37 33,280 5.33 33,280 5.01 33,280 4.60 33,280 3.76 33,280 2.84 36,480 3.11 40,320 3.31
21 70 25,600 5.60 28,800 5.56 32,000 5.51 32,000 5.19 32,000 4.78 32,000 3.94 32,000 3.08 35,200 3.30 38,880 3.56
27 80 24,320 5.78 27,520 5.74 30,720 5.69 30,720 5.37 30,720 4.96 30,720 4.12 30,720 3.30 33,920 3.54 37,600 3.85
PKA-A36KA 38,000 3.41
16 60 31,920 6.31 35,720 6.25 39,520 6.20 39,520 5.83 39,520 5.35 39,520 4.37 39,520 3.30 43,320 3.62 47,880 3.86
21 70 30,400 6.52 34,200 6.47 38,000 6.41 38,000 6.04 38,000 5.57 38,000 4.58 38,000 3.59 41,800 3.84 46,170 4.14
27 80 28,880 6.73 32,680 6.68 36,480 6.63 36,480 6.25 36,480 5.78 36,480 4.80 36,480 3.84 40,280 4.12 44,650 4.48
Model Name
Capacity
Btu/h
Input
kW
Indoor
intake air
D.B.(°C)
Indoor
intake air
D.B.(°F)
Outdoor intake air °C/°F W.B.
-25/-13 -20/-4 -15/5 -10/14 -5/23 0/32 5/41 10/50 15/59
CA P.C. CA P.C. CA P.C. CA P.C. CA P.C. CA P.C. CA P.C. CA P.C. CA P.C.
PCA-A30KA 32,000 2.99
16 60 26,880 5.53 30,080 5.48 33,280 5.44 33,280 5.11 33,280 4.69 33,280 3.83 33,280 2.90 36,480 3.18 40,320 3.38
21 70 25,600 5.72 28,800 5.67 32,000 5.62 32,000 5.30 32,000 4.88 32,000 4.02 32,000 3.15 35,200 3.36 38,880 3.63
27 80 24,320 5.90 27,520 5.86 30,720 5.81 30,720 5.48 30,720 5.07 30,720 4.21 30,720 3.36 33,920 3.61 37,600 3.93
PCA-A36KA 38,000 3.27
16 60 31,920 6.05 35,720 6.00 39,520 5.95 39,520 5.59 39,520 5.13 39,520 4.19 39,520 3.17 43,320 3.48 47,880 3.70
21 70 30,400 6.25 34,200 6.20 38,000 6.15 38,000 5.79 38,000 5.34 38,000 4.40 38,000 3.44 41,800 3.68 46,170 3.97
27 80 28,880 6.45 32,680 6.40 36,480 6.35 36,480 6.00 36,480 5.54 36,480 4.60 36,480 3.68 40,280 3.95 44,650 4.29
Model Name
Capacity
Btu/h
Input
kW
Indoor
intake air
D.B.(°C)
Indoor
intake air
D.B.(°F)
Outdoor intake air °C/°F W.B.
-25/-13 -20/-4 -15/5 -10/14 -5/23 0/32 5/41 10/50 15/59
CA P.C. CA P.C. CA P.C. CA P.C. CA P.C. CA P.C. CA P.C. CA P.C. CA P.C.
PCA-A30KA 32000 2.99
16 60 26880 5.53 30080 5.48 33280 5.44 33280 5.11 33280 4.69 33280 3.83 33280 2.90 36480 3.18 40320 3.38
21 70 25600 5.72 28800 5.67 32000 5.62 32000 5.30 32000 4.88 32000 4.02 32000 3.15 35200 3.36 38880 3.63
27 80 24320 5.90 27520 5.86 30720 5.81 30720 5.48 30720 5.07 30720 4.21 30720 3.36 33920 3.61 37600 3.93
PCA-A36KA 38000 3.27
16 60 31920 6.05 35720 6.00 39520 5.95 39520 5.59 39520 5.13 39520 4.19 39520 3.17 43320 3.48 47880 3.70
21 70 30400 6.25 34200 6.20 38000 6.15 38000 5.79 38000 5.34 38000 4.40 38000 3.44 41800 3.68 46170 3.97
27 80 28880 6.45 32680 6.40 36480 6.35 36480 6.00 36480 5.54 36480 4.60 36480 3.68 40280 3.95 44650 4.29
Model Name
Capacity
Btu/h
Input
kW
Indoor
intake air
D.B.(°C)
Indoor
intake air
D.B.(°F)
Outdoor intake air °C/°F W.B.
-25/-13 -20/-4 -15/5 -10/14 -5/23 0/32 5/41 10/50 15/59
CA P.C. CA P.C. CA P.C. CA P.C. CA P.C. CA P.C. CA P.C. CA P.C. CA P.C.
PEAD-A30AA 32,000 2.75
16 60 26,880 5.09 30,080 5.04 33,280 5.00 33,280 4.70 33,280 4.32 33,280 3.53 33,280 2.66 36,480 2.92 40,320 3.11
21 70 25,600 5.26 28,800 5.21 32,000 5.17 32,000 4.87 32,000 4.49 32,000 3.70 32,000 2.89 35,200 3.09 38,880 3.34
27 80 24,320 5.43 27,520 5.39 30,720 5.34 30,720 5.04 30,720 4.66 30,720 3.87 30,720 3.09 33,920 3.32 37,600 3.61
PEAD-A36AA 38,000 3.15
16 60 31,920 5.83 35,720 5.78 39,520 5.73 39,520 5.39 39,520 4.94 39,520 4.04 39,520 3.05 43,320 3.35 47,880 3.56
21 70 30,400 6.02 34,200 5.97 38,000 5.92 38,000 5.58 38,000 5.14 38,000 4.23 38,000 3.31 41,800 3.54 46,170 3.82
27 80 28,880 6.22 32,680 6.17 36,480 6.12 36,480 5.78 36,480 5.34 36,480 4.43 36,480 3.54 40,280 3.81 44,650 4.14
Model Name
Capacity
Btu/h
Input
kW
Indoor
intake air
D.B.(°C)
Indoor
intake air
D.B.(°F)
Outdoor intake air °C/°F W.B.
-25/-13 -20/-4 -15/5 -10/14 -5/23 0/32 5/41 10/50 15/59
CA P.C. CA P.C. CA P.C. CA P.C. CA P.C. CA P.C. CA P.C. CA P.C. CA P.C.
PEA-A18AA×2 38000 3.15
16 60 31920 5.83 35720 5.78 39520 5.73 39520 5.39 39520 4.94 39520 4.04 39520 3.05 43320 3.35 47880 3.56
21 70 30400 6.02 34200 5.97 38000 5.92 38000 5.58 38000 5.14 38000 4.23 38000 3.31 41800 3.54 46170 3.82
27 80 28880 6.22 32680 6.17 36480 6.12 36480 5.78 36480 5.34 36480 4.43 36480 3.54 40280 3.81 44650 4.14
Note: CA : Capacity (Btu/h) P.C. : Power consumption (kW)
D.B. : Dry-bulb temperature W.B. : Wet-bulb temperature
