4 - 81 4 - 81
4 SFC PROGRAM CONFIGURATION
MELSEC-Q
4.5.6 “Number of active steps” register
The “number of active steps” value for a given block is stored at this register.
(1) The “number of active steps” value for a given block is stored.
S
pecified device
D
Number of steps
(2) The number of active steps applies to the following steps.
• Normal active steps
• Coil HOLD steps
• Operation HOLD steps (without transition check)
• Operation HOLD steps (with transition check)
• Stopping steps
• Step double START waiting steps

Mitsubishi Q Series Specifications

General

I/O Points	Up to 4096 points
Communication	Ethernet, RS-232, RS-485
I/O Modules	Digital, Analog, Specialized
Programming Language	Function Block Diagram, Structured Text
Power Supply	24V DC, 100-240V AC
Operating Temperature	0°C to 55°C
Shock Resistance	147 m/s2 acceleration, 3 times in each of X, Y, and Z directions
Program Capacity	Up to 252K steps
