4.4.5 Active step batch readout (BMOV)
Usable Devices Programs Using Instructions Execution Site
Internal Device
(System, User)
Link Direct
J
\
SFC Program
Bit Word
File
Register
R
Bit
Wor
d
Intelligent
Function
Module
U
\G
Index
Z
Constant
K, H
Expansion
SFC
BLm\Sn
Other
Sn
Data
Type
Sequence
Program
Step
Transition
Condition
Block Step
Transition
Condition
S
D
n
BIN16
: Only step relay (S) can be used
n is a step No.
BMOV(P) (K4Sn)
S
D
n
m is a block No. and n is a step No.
BMOV(P) (BLm\K4Sn)
S D
n
[Function]
(1) A batch readout (designated number of words) of step operation statuses is executed at the
specified block.
(2) The readout results are stored at the “D” device as shown below.
b5
0/1 0/1 0/1 0/1 0/1 0/1 0/1 0/1 0/1 0/1 0/1 0/1 0/1 0/1 0/1 0/1
b15 b14 b13 b12 b11 b10 b9 b8 b7 b6 b4 b3 b2 b1 b0
Step designated at Sn
Step S(n+1)
Step S(n+15)
D
0: Step in question is inactive
1: Step in question is active
0/1 0/1 0/1 0/1 0/1 0/1 0/1 0/1 0/1 0/1 0/1 0/1 0/1 0/1 0/1 0/1
Step S(n+16)Step S(n+31)
D
+1
0/1 0/1 0/1 0/1 0/1 0/1 0/1 0/1 0/1 0/1 0/1 0/1 0/1 0/1 0/1 0/1
Step S(n+ (A 16))
Step S(n+ (A 16 + 15))
D +A
(3) The bit corresponding to the unassigned step No. (nonexistent step No.) in the read data turns
to "0".
