2 SYSTEM CONFIGURATION
MELSEC-Q
2. SYSTEM CONFIGURATION
(1) Applicable CPUs
MELSAP-L (SFC program) runs on the following CPU modules.
CPU Type Model Name Restriction
Basic model QCPU Q00JCPU, Q00CPU, Q01CPU
Product whose first
five digits of serial No.
are 04122 or later is
compatible.
High Performance model QCPU Q02CPU, Q02HCPU, Q06HCPU, Q12HCPU, Q25HCPU
Process CPU Q02PHCPU, Q06PHCPU, Q12PHCPU, Q25PHCPU
Redundant CPU Q12PRHCPU, Q25PRHCPU
Universal model QCPU
Q02UCPU, Q03UDCPU, Q04UDHCPU,
Q06UDHCPU,Q13UDHCPU,Q26UDHCPU, Q03UDECPU,
Q04UDEHCPU, Q06UDEHCPU, Q13UDEHCPU,
Q26UDEHCPU
(2) Peripheral devices for SFC program
The following peripheral devices can be used to create, edit and monitor SFC programs.
Compatible CPU
Software Package Model
Name for Personal Computer
Basic model
QCPU
High
Performance
model QCPU
Process CPU Redundant CPU
Universal model
QCPU
SW4D5C-GPPW-E or later
GX Developer Version 7.10L
(SW7D5C-GPPW-E) or later
2
GX Developer Version 8
(SW8D5C-GPPW-E) or later
2
GX Developer Version 8.18U
(SW8D5C-GPPW-E) or later
2
GX Developer Version 8.48A
(SW8D5C-GPPW-E) or later
2 1
GX Developer Version 8.62Q
(SW8D5C-GPPW-E) or later
2 3
GX Developer Version 8.68W
(SW8D5C-GPPW-E) or later
: Usable, : Unusable, : Partly usable
1: It can be used only with the Q02UCPU, Q03UDCPU, Q04UDHCPU, and Q06UDHCPU.
2: It can be used only with the Q12PHCPU, Q25PHCPU.
3: It can be used only with the Q02UCPU, Q03UDCPU, Q04UDHCPU, Q06CDHCPU, Q13UDCPU and
Q13UDHCPU.
2

Mitsubishi Q Series Specifications

General

I/O Points	Up to 4096 points
Communication	Ethernet, RS-232, RS-485
I/O Modules	Digital, Analog, Specialized
Programming Language	Function Block Diagram, Structured Text
Power Supply	24V DC, 100-240V AC
Operating Temperature	0°C to 55°C
Shock Resistance	147 m/s2 acceleration, 3 times in each of X, Y, and Z directions
Program Capacity	Up to 252K steps
