3
SEQUENCE PROGRAM CONFIGURATION AND
EXECUTION CONDITIONS
3.1 Sequence Program
3.1.3 Interrupt programs
3 - 21
1
Overview
2
Performance
Specification
3
Sequence Program
Configuration and
Execution Conditions
4
I/O Nunber Assignment
5
Memories and Files
Handled by CPU Module
6
Functions
7
Communication using
built-in Ethernet ports of
CPU module
8
Communication with
Intelligent Function
Module
Remark
Refer to the following manual for the block guarantee of cyclic data per station.
CC-Link IE Controller Network Reference Manual
Q Corresponding MELSECNET/H Network System Reference Manual
(PLC to PLC network)
Q Corresponding MELSECNET/H Network System Reference Manual
(Remote I/O network)
(g) Interrupt during END processing
When the constant scan is set and an interrupt factor occurs during the wait time
in the END processing, an interrupt program corresponding to the interrupt factor
is executed.
(5) Save and restoration of index register data and file register No.
When an interrupt program is executed by default of the CPU module, the index
register data and file register block No. are saved and restored at the time of switching
between the scan execution type program/low speed execution type program
Note3.12
and the interrupt program.( Section 10.6.4)Note12
(6) High speed execution setting and overhead time of interrupt program
When the "High speed execution" item for interrupt programs is checked on the PLC
system tab of PLC parameter in GX Developer, the index registers are neither saved
nor restored at the time of switching from the main routine program to the interrupt
program.
This reduces the overhead time of the interrupt program.( CHAPTER 11)
Note12
Basic
Universal
UD
Note3.12
Redundant
Note3.12
Note3.12
The Basic model QCPU, Redundant CPU and Universal model QCPU cannot be use low speed
execution type program.
Basic
Universal
UD
Note3.12
Redundant
Note3.12
Note3.12
