MEMORIES AND FILES USED IN CPU MODULE
5.2 High Performance Model QCPU, Process CPU, Redundant CPU, Universal Model QCPU
5.2.9 Execution of standard ROM/memory card programs (boot run)
5 - 53
1
Overview
2
Performance
Specification
3
Sequence Program
Configuration and
Execution Conditions
4
I/O Nunber Assignment
5
Memories and Files
Handled by CPU Module
6
Functions
7
Communication using
built-in Ethernet ports of
CPU module
8
Communication with
Intelligent Function
Module
(5) Changing the program file during RUN
Note5.13
Note11
(a) Changing method
During RUN of the High Performance model QCPU, Process CPU or Universal
model QCPU, files can be added, changed and deleted from the standard ROM or
memory card to the program memory with the following instructions in a sequence
program.
• PLOADP instruction (program transfer from memory card to program
memory)
• PUNLOADP instruction (program deletion from program memory)
• PSWAPP instruction (program deletion from program memory and program
transfer from memory card to program memory)
Refer to the following manual for details of the PLOADP instruction, PUNLOADP
instruction and PSWAPP instruction.
QCPU (Q Mode)/QnACPU Programming Manual (Common Instructions)
(b) Program setting made when program file is changed
Even if a program file has been changed during RUN of the High Performance
model QCPU, Process CPU or Universal model QCPU, the program setting in the
PLC parameter dialog box is not changed.
Hence, when the High Performance model QCPU, Process CPU or Universal
model QCPU is set to a STOP status, correct the program setting of the PLC
parameter dialog box to the current settings made during RUN of the High
Performance model QCPU, Process CPU or Universal model QCPU (addition/
change/deletion of program name).
Otherwise, an error will occur when the CPU is switched from STOP to RUN
status.
Note11
Universal
UD
Note5.13
Redundant
Note5.13
Redundant CPU and Universal model QCPU cannot change the program file during RUN using
the PLOADP instruction, PUNLOADP instruction, and PSWAPP instruction.
Note5.13
Redundant
Universal
UD
Note5.13
