App. - 7 App. - 7
MELSEC-Q
APPENDIX
Control data
1
of Q64AD (2/2)
Device Item Set data Setting range Set by
(S) + 10 CH4 Industrial shipment settings offset value — — System
(S) + 11 CH4 Industrial shipment settings gain value — — System
(S) + 12 CH1 User range settings offset value — — System
(S) + 13 CH1 User range settings gain value — — System
(S) + 14 CH2 User range settings offset value — — System
(S) + 15 CH2 User range settings gain value — — System
(S) + 16 CH3 User range settings offset value — — System
(S) + 17 CH3 User range settings gain value — — System
(S) + 18 CH4 User range settings offset value — — System
(S) + 19 CH4 User range settings gain value — — System
1 Set only the pass data classification setting (S)+2. If data is written to the area set by the system, the offset/gain values
will not be read properly.
Control data
2
of Q68ADV (1/2)
Device Item Set data Setting range Set by
(S) System area — — —
(S) + 1 Completion status
Stores the status when the instruction
is complete.
0 : Normal completion
Other than 0: Abnormal completion
—System
(S) + 2
(S) + 3
System area — — —
(S) + 4 CH1 Industrial shipment settings offset value — — System
(S) + 5 CH1 Industrial shipment settings gain value — — System
(S) + 6 CH2 Industrial shipment settings offset value — — System
(S) + 7 CH2 Industrial shipment settings gain value — — System
(S) + 8 CH3 Industrial shipment settings offset value — — System
(S) + 9 CH3 Industrial shipment settings gain value — — System
(S) + 10 CH4 Industrial shipment settings offset value — — System
(S) + 11 CH4 Industrial shipment settings gain value — — System
(S) + 12 CH5 Industrial shipment settings offset value — — System
(S) + 13 CH5 Industrial shipment settings gain value — — System
(S) + 14 CH6 Industrial shipment settings offset value — — System
(S) + 15 CH6 Industrial shipment settings gain value — — System
(S) + 16 CH7 Industrial shipment settings offset value — — System
(S) + 17 CH7 Industrial shipment settings gain value — — System
(S) + 18 CH8 Industrial shipment settings offset value — — System
(S) + 19 CH8 Industrial shipment settings gain value — — System
(S) + 20 CH1 User range settings offset value — — System
(S) + 21 CH1 User range settings gain value — — System
(S) + 22 CH2 User range settings offset value — — System
(S) + 23 CH2 User range settings gain value — — System
(S) + 24 CH3 User range settings offset value — — System
(S) + 25 CH3 User range settings gain value — — System
(S) + 26 CH4 User range settings offset value — — System
(S) + 27 CH4 User range settings gain value — — System
(S) + 28 CH5 User range settings offset value — — System
(S) + 29 CH5 User range settings gain value — — System
2 Setting is not necessary. If setting is made, the offset/gain values will not be read properly.
