5 - 6 5 - 6

MELSEC-Q

5 UTILITY PACKAGE (GX Configurator-AD)

(2) Data to be created with the utility package

The data and files shown below that are created with the utility package are also

processed using GX Developer operation. Figure 5.1 shows which operation

processes which data or file.

(a) This data is created with the automatic refresh setting, and stored in the

intelligent function module parameter file of the project to be created using

GX Developer.

Project

Program

Parameter

PLC Parameter

Network Parameter

Intelligent Function Module Parameter

(b) Steps 1) to 3) shown in Figure 5.1 are performed using the following

operations.

1) Operating from GX Developer.

[Project]

[Open existing project] / [Save project] / [Save project as]

2) Operating from the utility parameter setting module selection screen.

[File]

[Open file] / [Save file]

3) Operating from GX Developer.

[Online]

[Read from PLC] / [Write to PLC] "Intelligent function

module parameters"

Or, operate from the utility parameter setting module selection screen.

[Online]

[Read from PLC] / [Write to PLC]
