Mitsubishi S6R2 Series User Manual

1-6
Chapter 1 GENERAL
Left Side View
Right Side View
Governor
Governor oil filter
Fuel injection pump
Fuel filter
Oil cooler
Oil filler
Rear
Front
Front hanger
Breather
Rear hanger
Water pump
Note: Configuration varies depending on the destination and specifications.
S6R-PTK
Fuel feed pump
Stop solenoid
Oil level gauge
Fuel return port
Fuel inlet
Damper
Oil filter
Bypass oil filter
Starter
Engine air cooler
coolant outlet
Air cooler
Engine air cooler
coolant inlet
Turbocharger
Front
Rear
Exhaust manifold
Alternator
S6R-PTK
Note: Configuration varies depending on the destination and specifications.
Exhaust pipe, exhaust outlet
Air inlet
Relief valve
