11-4
Chapter 11 INLET AND EXHAUST SYSTEMS
Inlet System - Remove and Inspect
Sea water air cooler spec
1
2
3
4
Replace
Replace
Replace
Removing Sequence
1 Cover
2 Connector
3 Duct
4 Air cooler (Approx 100 kg [220 lb])
