Mitsubishi TDJ300D User Manual

4. Name of each component
(1) Refrigeration unit
(2) Controller
(3) Compressor
(a) TDJ300D
(b) TDJ430D
(4) Motor pack (only for type 2)
(5) Power source box (only for type 2)
– 5 –
Discharge
service valve
Suction
service valve
Magnet clutch
Discharge
service valve
Magnet clutch
Suction
service valve
Limit switch
Power source outlet
Power source
indication lamp
Alarm indication lamp
(Motor overcurrent relay
active indicator)
Fuses
Manual reset button
(For motor overcurrent relay)
Compresso
r
Alarm lamp
(red)
Defrost switch
Defrost indication lamp
(orange)
Operation indication lamp
(green)
Display indication lamp
(green)
Operation switch
Display switch
Alarm switch
Digital display
Hours switch
Hours indication lamp
(green)
Temperature setting
switches
