22 23
TCHT011
9-6-2. DC Fan Motor (fan motor/indoor controller circuit board)
Notes
· High voltage is applied to the connecter (CNMF) for the fan motor. Pay attention to the service.
· Do not pull out the connector (CNMF) for the motor with the power supply on.
(It causes trouble of the indoor controller circuit
board and fan motor.)
Self check
Symptom : The indoor fan cannot rotate.
Yes
Fail
Fail
Wiring contact check
Contact of fan motor connector (CNMF)
Power supply check (Remove the connector (CNMF))
Measure the voltage in the indoor controller circuit
board.
TEST POINT
1 : VDC (between 1 (+) and 3 (−) of the fan connector): VDC 294–325 V DC
TEST POINT 2 : VCC (between 4 (+) and 3 (−) of the fan connector): VCC 15 V DC
Wiring recovery
Replace the indoor controller board.
Replace the fan motor.
Replace the indoor
controller board.
Replace the fan motor.
Is the voltage normal?
Is there contact failure?
No
1
2
Yes
No
Check the operation of fan. END
Yes
OK
Check the operation END
OK
Check method of DC fan motor (fan motor/indoor controller circuit board)
Sensor signal check
Measure the voltage between CNMF
6 and 3 0 V DC
and 15 V DC in the indoor controller circuit board.
Does the voltage repeat
0 V DC and 15 V DC?
No
Yes
Indoor controller board fuse check
Is the fuse normal?
Replace
the fuse.
Check the operation END
OK
Replace the indoor
controller board.
Check the operation
END
OK
Fail
Replace the fan motor.
Yes
No
Fail
To Next Page
