MODELS: WD-57733 / WD-65733 / WD-73733 / WD-57734 / WD-65734 / WD-73734 / WD-C657
WD-Y577 / WD-Y657 / WD-57833 / WD-65833 / WD-73833
QUICK REFERENCE FOR COMMON PARTS
Lamp-Cartridge 915P061010
Unit-Lamp-Ballast 938P076010
Speaker 480P084010
Fan-Exhaust 299P310020
Fan-Scirocco (Ballast) 299P321010
Fan-Engine (DMD) 299P322010
Sensor-Temperature 299P323010
PWB-Sw-Lamp 935D942001
All Models
MODEL PWB-TERMINAL PWB-MAIN PWB-POWER
WD-57733
934C259001 934C260002 934C261001
WD-57734
" 934C260001 "
WD-57833
934C259002 934C265001 "
WD-Y577
934C259001 934C260001 "
WD-65733
" 934C260002 "
WD-65734
" 934C260001 "
WD-65833
934C259002 934C265001 "
WD-C657
934C259001 934C260003 "
WD-Y657
" 934C260001 "
WD-73733
" 934C260002 "
WD-73734
" 934C260001 "
WD-73833
934C259002 934C265001 "
PWB's
MODEL OPTICAL ENGINE
LENS
FRESNEL
SCREEN
LENTICULAR
MIRROR REMOTE
WD-57733 938P075010 491P206050 491P207050 767D084010 290P137010
WD-57734
938P075040 " " " "
WD-57833
" " " " 290P137020
WD-Y577 938P075010 " " " 290P137010
WD-65733
938P075020 (1) (1) 767D084020 "
WD-65734 938P075050 (1) (1) " "
WD-65833
" 491P206040 491P208050 " 290P137020
WD-C657 938P075020 (1) (1) 767D085020 290P137010
WD-Y657 "(1)(1)""
WD-73733
938P075060 491P206070 491P208020 767D084030 "
WD-73734 """""
WD-73833
" " " " 290P137020
(1) Refer to Screen Parts list, pages 47 & 48
OPTICAL ENGINE & MISC. PARTS.
