MODELS: WD-57733 / WD-65733 / WD-73733 / WD-57734 / WD-65734 / WD-73734 / WD-C657 / WD-Y577
WD-Y657 / WD-57833 / WD-65833 / WD-73833
Page 7
Back Cover Removal
Back Cover Removal Procedure
1) Remove 10 screws (A) from the back cover
(11 IN 73” models)..
2) Pull the back cover from the TV.
Back Cover Installation
Reverse the removal procedure but install
the Lamp Cover Last.
Chassis Removal
Chassis Removal
1) Remove four screws (A)
2) Disconnect all cables connecting to the chassis.
3) Carefully slide the chassis out of the Cabinet.
V36 & V377
V387
V36 / V37 / V38
DISASSEMBLY
To Next Page
