Mitsubishi XD3500U - User Manual

Questions and Answers

J
Jeanette TranAug 19, 2025
What to do if my Mitsubishi XD3500U Projector says “NO SIGNAL”?
- M
  Mike ValenciaAug 19, 2025
  If your Mitsubishi Projector displays “NO SIGNAL”, consider these steps: * Turn on the connected device and check its functionality. * Verify that the external device is outputting signals. * Inspect the cable connecting the projector to the external device for any defects. * Ensure the projector is connected to the external device using the correct terminals. * Confirm that the connected device is correctly selected as the input source. * If using an extension cord, replace it with the supplied cable to check for correct image projection. If it works, use an RGB signal amplifier with the extension cord.
A
Aaron DouglasAug 21, 2025
How do I fix blurred images on my Mitsubishi XD3500U Projector?
- R
  Rachel HansenAug 21, 2025
  To correct blurred images on your Mitsubishi Projector: * Adjust the focus. * Clean the lens. * Press the W or X button on the remote control to eliminate flicker. * Adjust TRACKING and FINE SYNC in the SIGNAL menu. * Adjust BRIGHTNESS and CONTRAST in the QUICK MENU or IMAGE menu. * Ensure the projector and screen are perpendicular to each other.
K
Katie PhillipsAug 25, 2025
Why are the projected images shaking or displaced on my Mitsubishi XD3500U?
- J
  Jordan EdwardsAug 25, 2025
  If projected images are shaking or displaced on your Mitsubishi Projector: * Check the cable connected to the external device for intermittency. * Ensure the cable’s plug is firmly connected to the external device’s connector. * Project an image with many characters, like a help menu, and press the AUTO POSITION button. * If the computer outputs out-of-spec signals, adjust the SIGNAL menu.
S
Stephanie KleinAug 27, 2025
How to brighten dark projected images on a Mitsubishi XD3500U Projector?
- O
  Oscar KingAug 27, 2025
  If the projected images from your Mitsubishi Projector are dark, try the following: * Adjust BRIGHTNESS and CONTRAST in the QUICK MENU or IMAGE menu. * Consider replacing the lamp.
M
Margaret KingAug 30, 2025
Why is there no audio output from my Mitsubishi XD3500U Projector?
- M
  Mary CummingsAug 31, 2025
  If there is no audio output from your Mitsubishi Projector: * Check that the volume isn’t set too low. * If the external device is connected with an HDMI cable, set the audio output of the device to PCM output.
R
russostephenSep 2, 2025
What does it mean when my Mitsubishi Projector displays “TEMPERATURE!!”?
- E
  edward45Sep 3, 2025
  If your Mitsubishi Projector displays “TEMPERATURE!!”, take the following actions: * Eliminate any causes of the rise in ambient temperature. * Remove any objects blocking the air inlet or outlet grille.
M
Mrs. Victoria PetersonSep 5, 2025
How to correct distorted projected images on a Mitsubishi XD3500U?
- D
  douglas09Sep 5, 2025
  To correct distorted projected images on your Mitsubishi Projector, adjust the projector and the screen so that they are perpendicular to each other.
D
Denise KingSep 8, 2025
What to do if the menu can’t be used on Mitsubishi XD3500U Projector?
- L
  Lisa CookeSep 8, 2025
  If the menu on your Mitsubishi Projector can’t be used, turn off the main power, wait about 10 minutes, and then turn the main power back on.
W
Wendy RodriguezSep 12, 2025
Is it normal for my Mitsubishi XD3500U Projector exhaust vents to emit warm air?
- A
  annettegarciaSep 12, 2025
  The warm air emitted from the exhaust vents of your Mitsubishi Projector is normal. It is the result of the projector cooling its internal components and is not a malfunction.
F
fescobarNov 14, 2025
How to fix a Mitsubishi Projector when no image appears on the screen?
- M
  Michael WestNov 15, 2025
  If no image appears on the screen of your Mitsubishi Projector, try the following: * Cancel AV mute by pressing the AV MUTE button. * Ensure the lens cap is removed. * Allow about 1 minute for the lamp to light up. The lamp may fail to light up on rare occasions, so wait a few minutes and try again. * If the projector was turned off before the lamp cooled down, and the POWER button doesn't work after turning on the main power, wait for the fan to stop, then press the POWER button. * Set SCART INPUT to OFF in the QUICK MENU or FEATURE menu. * Ensure the intake vent is clean. * Check the cables connected to external devices for damage. * If using an extension cable, replace it with the supplied cable. If images display correctly, add an RGB signal amplifier to the extension ...

Summary

Important safeguards

Setting up your projector

Setting up the screen

Provides guidance on positioning the projector and screen for optimal projection.

Screen size and projection distance

Offers a table to determine screen size, projection distance, and lens shift.

Viewing computer images

Connecting the projector to a computer

Guides on connecting computers via analog RGB, DVI, and audio inputs.

Plugging the power cord

Instructions on safely connecting the projector's power cord to an outlet.

Viewing video images

Connecting the projector to video equipment

Guides on connecting video players, S-video, BNC, and composite sources.

Projector + DVD player or HDTV decoder

Instructions for connecting DVD players or HDTVs using component video inputs.

Connection (for video equipment having an HDMI terminal)

Details on connecting devices with HDMI output for video and audio.

Connection (for video equipment having a DVI-D terminal)

Details on connecting devices with DVI-D output for video and audio.

Plugging in the power cord

Instructions for safely connecting the projector's power cord.

Projecting images

Step-by-step guide to turn on the projector and display video images.

Menu operation

IMAGE menu

Describes image adjustment settings like color, brightness, sharpness, and advanced options.

INSTALLATION menu

Covers settings related to projector installation, standby mode, and image reversal.

FEATURE menu

Details feature settings such as aspect ratio, password lock, and video signal selection.

SIGNAL menu

Explains settings for signal resolution, frequency, position, and noise reduction.

Adjusting projected images

To adjust the brightness (CONTRAST and BRIGHTNESS)

To adjust the color (COLOR and TINT)

To sharpen or soften the projected image (SHARPNESS)

To adjust the tone of white (COLOR TEMP.)

Color Enhancer

How to adjust the computer image

Provides a flowchart for troubleshooting and adjusting computer image display issues.

Simple method to adjust the image position

Indicators

Normal condition

Abnormal condition

Lists abnormal indicator states and their corresponding solutions or issues.

Replacing the lamp

Interval of lamp replacement

To replace the lamp:

Step-by-step instructions for safely removing and installing the projector lamp.

Reset of the lamp operation time

Details the procedure to reset the lamp operating time after replacement.

When removing the lamp from the ceiling-mounted projector

Troubleshooting

Power can not be turned on.

Solutions for issues where the projector fails to power on.

No image appears on the screen.

Troubleshooting steps for when no image is displayed on the screen.

Images are not displayed correctly.

Addresses issues like image shaking, displacement, distortion, and color problems.

Troubleshooting Display Issues

Covers further display problems including incorrect color tint and obscured images.

Mitsubishi XD3500U Specifications

General

Resolution	1024 x 768 (XGA)
Contrast Ratio	2000:1
Throw Ratio	1.7 - 2.1:1
Zoom Ratio	1.2x
Projection Size	40 - 300 inches
Lamp Life	2000 hours (Normal Mode)
Input Ports	S-Video, Composite Video
Keystone Correction	Vertical: ± 30 degrees
Output Terminals	D-Sub 15 pin x 1, Audio Mini Jack x 1
