MK MK-101 - Parts List for MK-101 Saw

MK-101 w/JCS Stand Revision 04/05, Effective Date August 19, 2005 Page 43
EXPLODED VIEW AND PARTS LIST
PARTS LIST:
Item Description
Qty
Part # *Rev
A Accessories
- - -
A1 Carton, Accessory Pack, 10 1 153366 *
A2 Foam, Accessory Pack Carton 1 154022 *
A3 Wrench, 15/16 Closed End 1 134684 *
A4
A5
A6
Guard, Splash
Wingscrew, 1/4-20 X 1/2
Washer, 1/4 SAE Flat
1
1
1
160310
151888
151915
*
A7
A8
A9
A10
Pump, Water, G-150A
Fitting, Plastic, 1/4 FNPT X 1/4 BARB
Hose, Vinyl, 1/4 ID
Clamp, Flow, 1/4-1/2
1
1
6’
1
151271
128397
132951
154394
*
A11 Rip Guide, Large Die Cast 1 159751 *
A12 Miter, Large Bullnose 1 153201 *
A13 Owner’s Manual, MK-101 Portable Tile Saw 1 162059 *
A14 Card, MK Warranty Registration 1 155037 *
A15 Label, Do Not Return 1 157063 *
A16 Sell Sheet, Tile Accessory 1 156915 *
A17 Blade, MK-100, 10 X 060 X 5/8 1 154380 *
A18 Tag, Serial Number, Blank 1 157500 *
A19 Clip, Table Lock, 30 deg 1 160331-1 *
A20 Pan, Plastic, 101 1 150634 *
A21 Plug, Rubber Drain 1 153439 *
A22 Clamp, Holding , Pump 1 162054 *
A23 Screw. Wing, ¼-20 x ½ 2 151888 *
A24 Nut, Hex, ¼-20 2 151893 *
A25 Sheet, Set Up Instructions (Not shown in Exploded View) 1 162082
C Frames
- - -
C1 Assembly, Portable Stand 1 160705 *
D Posts
- - -
D1 Post, DC, 101, MK Red 1 158438 *
D2 Shaft, 10.63” Pivot, 101 1 153254 *
D3 Screw, 3/8-16 X 1/2 Socket Head Set 1 153710 *
D4 Spacer, 5/8X.385X1.4 2 160654 *
D5 Screw, 3/8-16 X 2 1/2 Hex Head Cap 2 156030 *
D6 Washer, 3/8 Split Lock 2 150925 *
D7 Knob, 3/8-16 X 1.5 MK Adjustment 1 156770-02 *
D8 Washer, 3/8 SAE Flat 3 150923 *
D9 Plastic Post Cover 1 160157
E Stop, Cutting Head
Kit, Stop 10” Cutting Head
1 157728-MK
E1 Stop, 10” Cutting Head 1 157728 *
E2 Screw, 1/4-20 X 1 1/4 Hex Head Cap 1 157145 *
E3 Washer, 1/4 Split Lock 1 152591 *
E4 Sheet, Cutting Head Stop Instruction 1 157728-IS *
F Belt Guards - - -
F1 Belt Guard, MK-101 1 158319-01 *
F2 Bracket, Inner Belt Guard, 100/101 1 158611 *
F3 Screw, 1/4-20 x 3/4 Hex Head Cap 3 152370 *
F4 Screw, 1/4-20 x 1 Hex Head Cap 1 152676 *
F5 Washer, 1/4 Split Lock 4 152591 *
