MK-101 w/JCS Stand Revision 04/05, Effective Date August 19, 2005
Page 44
EXPLODED VIEW AND PARTS LIST
F6 Washer, 1/4 SAE Flat 4 151915 *
F7 Belt, 260J6 Micro-V 1 158194 *
G Assembly, Blade Guard 1 152582
G1 Blade Guard, 101/115 1 153659 *
G2 Tube, Water 2 155389 *
G3 Screw, 5/16-18 X 1/2 Socket Head Set 3 152607 *
G4
Elbow, 1/8 MNPT X 1/4 BARB 90° Brass
1 154652 *
H Motors - - -
H1 Motor, 1-1/2HP\120V\60Hz 1 160127 *
H2 Pulley, 6J17 X 5/8 Bore 1 158214 *
H3 Key, 3/16 x 3/16 x 1-1/8 Square 1 150344 *
H4 Screw, 5/16-18 X 3/8 Socket Head Set, Cup Point 2 157083 *
H5 Label, Warning most motor..., 2 3/4 X 2 7/16 1 155672 *
H6 Label, Caution, GFCI, 1 X 2 1/8 1 155678 *
H7 Label, Caution, 5 Amp Max., 1 X 2-1/8 1 154822 *
H8 Label, Warning, Read Owner’s Manual, 1-3/4 X 3-3/8 1 155806 *
H9 Label, MK Service Info., 2 1/8 X 1-13/16 1 155038 *
J
Assembly, Cutting Head
1 158191 -
J1 Cutting Head, DC, 100/101, MK Red 1 158224 *
J2 Pin, Blade Shaft Lock 1 158200 *
J3 Spring, Blade Guard Lock 1 158201 *
J4 E-Ring, 1/4 Retaining 1 158202 *
J5 Bearing, 17mm X 40mm X 12mm Ball (6203-2NSE) 2 137711 *
J6 Shaft, Blade 100/101 1 158222 *
J7 Flange, 2-3/8 Inner 1 137737 *
J8 Flange, 2-3/8 Outer 1 135830 *
J9 Nut, 5/8-18 Hex 1 135848 *
J10 Pulley, 6J19 X 5/8 Bore 1 158199 *
J11 Key, 3/16 x 3/16 x 1 1/8 Square 1 150344 *
J12 Screw, 5/16-18 X 3/8 Socket Head Set, Cup Point 2 157083 *
J13 Bumper, 1/2 Dia Rubber 1 152674 *
J14 Screw, 5/16-18 X 1 Hex Head Cap 4 151743 *
J15 Washer, 5/16 SAE Flat 4 151754 *
J16 Washer, 5/16 Split Lock 4 151747 *
J17 Nut, 5/16-18 Hex 4 101196 *
J18 Screw, 5/16-18 x 2 1/2 Hex Head Cap, Full Thread 1 151748 *
J19 Pivot, Blade Guard 1 153208 *
J20 Washer, 3/8 SAE Flat 2 150923 *
J21 Wingnut, 5/16-18 Nylock 1 151746 *
J22 Strap, Motor Adjustment 1 152673 *
J23 Screw, 3/8-16 X 3 1/2 Hex Head Full Thread 1 153147 *
K Guide Bars
- - -
K1 Bar, 3/4 X 32 Guide, 101 1 134759 *
K2
Cover, Guide Bar, 120° X 35”
1 158403 *
K3 Spacer, Guide Bar Cover, 101 2 152393 *
K4 Screw, 5/16-18 X 1 Hex Head Cap 2 151743 *
K5 Washer, 5/16 Split Lock 2 151747 *
K6 Washer, 5/16 SAE Flat 2 151754 *
L Tables
- - -
L1 Table, 100/101 1 157660 *
L2 Washer, 5/16 SAE Flat 2 151754 *
