MK MK-101 - Parts List for JCS Stand

MK-101 w/JCS Stand Revision 04/05, Effective Date August 19, 2005
Page 45
EXPLODED VIEW AND PARTS LIST
L3 Washer, 5/16 Split Lock 2 151747 *
L4 Screw, 5/16-18 X 1 Hex Head Cap 2 151743 *
M
Assembly, Roller Wheel
1 151756 -0-
M1 Bracket, Roller Wheel 1 154021 *
M2 Wheel, Roller 1 151799 *
M3 Screw, 1/4-20 X 1 1/2 Hex Head Cap 1 151914 *
M4 Washer, 1/4 SAE Flat 1 151915 *
M5 Nut, 1/4-20 Hex 1 151893 *
PARTS LIST FOR JCS STAND (SHOWN IN PAGE 41):
Item Description Qty
MK p/n
- Assembly, Portable Stand, MK100/101/770EXP 1 160705
1 Weldment, Integrated Frame 1 160690
2 Weldment, Rear Support 1 160693
3 Weldment, Front Support 1 160700
4 Spring, Gas, 600N 2 160696
5
Fitting, End, Gas Spring
4 160695
6 Washer, 5/16 SAE 10 151754
7 Nut, Hex, Nylok, 5/16-18 5 158289
8 Screw, Hex, 5/16-18x2 3 155494
9 Screw, Shoulder, 5/16x3/4 4 160726
10 Nut, Hex, Nylok, 1/4-20 4 159857
11 Spacer, 1/2x5/16x1-1/8 2 160732
12 Washer, 3/8 SAE 8 150923
13 Wheel, 8x2-1/4 2 155986
14 Spacer, 3/4x3/8x2-1/4 2 160728
15 Nut, Hex, Nylok, 3/8-16 4 152505
16 Screw, Hex Hd, 3/8-16x4 2 153531
17 Plug, Plastic, 1 SQ., 10-14 Ga 6 160727-2
18 Plug, Plastic, 1 SQ., 14-20 Ga 1 160727-1
19 Caster, Swivel, 3” w/ 3/8-16 Stem 2 160735
20 Bumper, Rubber 2 159855
21 Rivet, Dome Style, 3/16 Dia x.251-.375 Grip 2 160729-3
22 Screw, Hex Hd, 5/16-18x2-3/4 2 152520
23 Weldment, Vertical Support 1 160934
24 Plate, Spring 1 160694
25 Rivet, Dome Style, 5/32 Dia x.063-.125 Grip 4 161226-1
26 Pin, Locking 1 160936
27 Spring, 1/2x.04x1.75 1 160697
28 Ring, Retaining, 3/8x.035 1 161171
29 Knob, Plastic 1 159428-1
30 Pin, Frame Locking 1 162055
31 Pin, Wheel Locking 1 162051
32 Ring, Retaining, 1/2x.042 1 162053
33 Spring, .600x.045x2.25 1 162052
34 Cap, Vinyl, 1/2-9/16x3/4 3 162057
