MKS 1249A - Mounting Instructions; Figure 4: Front View Dimensions of the 1249 Unit; Figure 5: Side View Dimensions of the 1249 Unit

Chapter Two: Installation Setu
p
25
1.13
(28.7)
Figure 4: Front View Dimensions of the 1249 Unit
3.12
(79.2)
4.12
(104.6)
1.13
(28.7)
Figure 5: Side View Dimensions of the 1249 Unit
Mounting Instructions
The 1249 unit has four predrilled holes for mounting screws. Refer to Figure 3, page 24, for the
location and size of the mounting screw holes.
