The jumper settings for various system configurations are listed in Table 10.
Jumper Summary
Desired Settings Jumper Position
J3 J4 J5
0 to 5 VDC, TTL Logic VIN 0 to 5 V 5 VDC
*
0 to 10 VDC, TTL Logic VIN 0 to 10 V 5 VDC
*
0 to 5 VDC, Open Collector VIN 0 to 5 V O.C.
0 to 10 VDC, Open Collector VIN 0 to 10 V O.C.
4 to 20 mA, TTL Logic 4 - 20 0 to 5 V 5 VDC
*
4 to 20 mA, Open Collector 4 - 20 0 to 5 V O.C.
* Connect a 5 VDC supply to pin 14 on the Interface connector (refer to
Table 6, page 27).
Table 10: Jumper Summary
Labels
Serial Number Label
The serial number label lists the serial number and the product model code. The label also
displays the CE mark signifying compliance with the European CE regulations.
1249A
Serial #:
Model #:
0123456789
MKS Instruments, Inc. Made in the USA
Figure 8: Serial Number Label
