MKS SG 1024 - General Information and Safety; General Product Information; Safety Warnings and Precautions

File: SG1024_r1eng - April 2017 - Technical note: SG 1024 page 3 of 16
PM 250
SG 1024
Contents
A
Alarm troubleshooting 15
B
Bit alarm table 7
C
CE Declaration 1
Components layout 14
Components List 14
Conn.# 1 wiring 11
Conn.# 2 wiring 12
Conn.# 3 accessories 11
Conn. Fielbus 13
E
Environmental conditions 6
Equipment installation 5
Equipment ratings 5
F
Firmware upgrade 8
G
General description 4
General informations 3
H
Handling instructions 5
Handling warnings 4
How to order 16
M
Manual Commands 9
Meaning of external commands 7
Monitor signals 12
P
Physical characteristics 6
Physical dimensions 13
Power-up procedure 6
R
RoHS conformity 2
S
Software description 9, 10
T
Technical assistance 16
W
Warnings 3
Wiring instructions 6
Working modes 7
General Informations
ThisequipmentsatisestheEuropeanStandardEN61010-1
With reference to EN 61010-1 standard, note:
thisappliancemustbeinstalledandservicedonlybyqualied
personnel.
The appliance must only be used by persons acquainted with
the regulations covering the application.
Theequipmentdescribedinthismanualhasbeenclassiedas
industrial,scienticandmedical(ISM)radio-frequencyequip-
ment and the related standard for the Electromagnetic distur-
banceistheEN55011(Industrialscienticandmedical(ISM)
radio-frequency equipment - Electromagnetic disturbance
characteristics - Limits and methods of measurement.)
With reference to Basic Standard EN55011, this equipment
is included into Group 2 (Microwave generators, Thyristor
command equipment, Welding equipment, Induction heating
equipment or machine, Microwave industrial oven, etc.), Class
A (industrial environment): for this reason this equipment shall
not be used in the residential, commercial and light-industrial
environment.
The SG 1024, when properly installed, complies with the
limits of radio disturbance characteristic of a Group2, Class A
equipments as stated by EN55011.
WARNINGS & SAFETY RULES
The SG1024 is powered by main line: read this manual
carefully before using. Be sure of correct connections and
use.
The SG 1024 is a microwave generator producing near
1000 W at 2.45 GHz at its output on a coaxial socket.
People must not be exposed to microwave energy which
may be given off by the output socket for improper use
or misconnection. All microwave connections, couplings,

NEVER operate the generator without the connection
to a cavity, NEVER operate it without a load to absorb
microwave energy.
Failure to comply with the instructions enclosed in this
manual may involve considerable risks for the staff respon-
sible for checking and using the equipment, as well as the
risk of general malfunctions of the equipment itself.
