FR35 AC/DC Operation
15
6.10 Replacing the plug fuse (12/24 V)
➤ Pull the adapter sleeve (fig. 5 4, page 3) off of the plug.
➤ Unscrew the screw (fig. 5 5, page 3) out of the upper half of the housing
(fig. 5 1, page 3).
➤ Carefully raise the upper half of the housing from the lower (fig. 5 6,
page 3) half.
➤ Take out the contact pin (fig. 5 3, page 3).
➤ Replace the defective fuse (fig. 5 2, page 3) with a new one that has the
same rating (8A 32V).
➤ Re-assemble the plug in the reverse order.
I
6.11 Replacing the light bulb
➤ Press the switch pin (fig. 6 2, page 3) downwards so that the transparent
part (fig. 6 1, page 3) of the lamp can be removed at the front.
➤ Replace the light bulb.
I
➤ Press the transparent part of the lamp back into the housing.
NOTE – Internal DC fuse
There is an additional DC fuse inside the device (Automotive stand-
ard blade fuse, 10 A). This fuse can only be replaced by an author-
ised repair centre.
NOTE
The LEDs in the light bulb must be aligned with the transparent part
of the lamp.
