MOBIUS TRIMMER M108S USER GUIDE
14
REMOVING LID:
12. Open lid by sliding the 2 latches towards
each other, and then rotating the lid
away from you
15. Lift each bed knife out of machine
and place to the side, preferably in a
Mobius Blade Rack
18. Rotate wheels outward and unlock
casters
20. Lift the machine straight up to clear
the wooden anchor below each wheel.
Walk the machine to the side until it clears
the crate-base. Set machine down and
re-`lock the wheels .Remove power cord
from crate base
13. Disconnect the wire between the lid
and the M108S body
16. Lift each spacer bar out of machine
and place to the side, preferably in a
Mobius Blade Rack
19. Remove the four retaining straps that
anchor the machine to the crate base.
Rotate the handles on each side of the
M108S outward.
Note: 4 people should lift the M108S off
the crate base with 1 person per handle
14. With two people, slowly rotate the lid
towards the closed position while pulling
up on it. When the hinges reach the
correct position, the lid will release from
the machine body. Place the lid aside.
17. Lift each helical blade out of machine
and place to the side, preferably in a
Mobius Blade Rack
For more in depth instructions, see the Academy video on lid removal.
REMOVING BLADE CARTRIDGES:
REMOVING MOBIUS TRIMMER BODY FROM CRATE BASE:
