Mobius Trimmer M108S - DRY TRIMMING

MOBIUS TRIMMER M108S USER GUIDE
28
• VFDs:
Blades: at full power (11)
Vacuum: Start at 3/4 power (approximately 7). Once the tumbler is ‘primed’ (i.e. 3/4
full, increase the vacuum until the desired trim quality is reached)
Tumbler: at full power (11)
• FEED RATE:
Once the tumbler is primed, you will likely run your infeed conveyor speed somewhere
in the range of 20 – 45. Adjust up or down as necessary to achieve desired trim quality.
If using an infeed hopper, aim to maintain a consistent feed rate once the tumbler is
primed and the desired trim quality has been dialed in
• TILT ANGLE:
Start with casters at the infeed end of the line approximately 4” off the oor. After the
tumbler has been primed and the feed rate has been dialed in for trim quality, adjust
the tilt angle up or down to maintain the tumbler at 3/4 full.
• TUMBLER FILL:
‘Priming’ the tumbler is critical for dry trimming. Priming the tumbler means to ll it as
rapidly as possible to 3/4 full. Once the tumbler is 3/4 full, dial back the feed rate as
described below, but always maintain a 3/4 full tumbler
TANDEM MOBIUS LINE
When dry trimming with a tandem Mobius line, try starting with the following parameters and adjust as
necessary to reach the desired trim quality:
• VFDs:
Blades: at full power (11)
Vacuum: Start at 3/4 power (approximately 7). Once the tumbler is ‘primed’ (i.e. 3/4
full, increase the vacuum until the desired trim quality is reached)
Tumbler: at full power (11)
• FEED RATE:
Once the tumbler is primed, you will likely run your infeed conveyor speed somewhere
in the range of 15 – 25. Adjust up or down as necessary to achieve desired trim quality.
If using an infeed hopper, aim to maintain a consistent feed rate once the tumbler is
primed and the desired trim quality has been dialed in.
• TILT ANGLE:
Start with casters at the infeed end of the line approximately 1” off the oor. After the
tumbler has been primed and the feed rate has been dialed in for trim quality, adjust
the tilt angle up or down to maintain the tumbler at 3/4 full
• TUMBLER FILL:
‘Priming’ the tumbler is critical for dry trimming. Priming the tumbler means to ll it as
rapidly as possible to 3/4 full. Once the tumbler is 3/4 full, dial back the feed rate as
described below.
SINGLE MOBIUS UNIT
When dry trimming with a single Mobius unit, try starting with the following parameters and adjust as
necessary to reach the desired trim quality:
DRY TRIMMING
