S15 Camera Manual: Product Overview
© MOBOTIX AG • Security-Vision-Systems • Made in Germany
www.mobotix.com • sales@mobotix.com
Technical Specifications Thermal Sensor Module
Lens Options L43 (45°), L65 (25°), L135 (17°)
(horizontal field of view)
Sensitivity NETD typ. 50mK (equals 0.05°C), <79mK
Image Sensor Uncooled microbolometer, 336x252 pixels, spectral range 7.5
to 13.5μm
Temperature
Measurement Range
–40 to +550°C/–40 to 1.022°F (temperature of the displayable
objects)
Max. Image Size Can be scaled up to 2048x1536 (QXGA), dual images are auto
-
matically scaled to size of the standard sensor module
Max. Frame Rate 9fps (when displaying a standard sensor module and a
thermal sensor module, the overall frame rate of the camera is
reduced to 9fps)
Software Features O-color/black & white image display, mirrored image,
obscured image areas, vPTZ (virtual pan/tilt/zoom), text and
logo display, display of event/action symbols, meter display
(bar chart or diagram), temperature control windows
Power Consumption Typ. 1.5W per Thermal Sensor Module
Operating Conditions IP66 (DIN EN 60529)
–30 to +60°C/–22 to +140°F (DIN EN 50155)
Dimensions Total length: 78mm, max. Ø: 63mm
Materials Module housing: Aluminum, black anodized;
Pressure plate: Stainless steel V2A
Weight <330g (one Thermal Sensor Module without sensor cable)
Technical Data S15D with Thermal Sensor Module
Image Formats
(per sensor)
Standard formats like Full HD, VGA, etc. up to 2048 x 1536
(QXGA) and custom formats
Alarm/Events Video Motion detection, MxActivitySensor, external signals,
shock detector, notification via e-mail, FTP, pre- and post-alarm
images
Operating Conditions IP65 (DIN EN 60529)
–30 to +60°C/–22 to +140°F (DIN EN 50155)
Power Consumption Depending on sensor modules used:
1 thermal, 1 optical: typ. 6.5W (briefly up to 7.5W possible)
2 thermal: typ. 7W (briefly up to 8W possible)
1 thermal: typ. 5.5W (briefly up to 6.5W possible)
Max. Power Consumption of
Attached Extension Modules
USB only: ≤1W
MxBus only: ≤1W
USB and MxBus: ≤2W
Power Supply Power-over-Ethernet (IEEE 802.3af);
PoE Class3 required
