S15 Camera Manual: Product Overview
© MOBOTIX AG • Security-Vision-Systems • Made in Germany
www.mobotix.com • sales@mobotix.com
S15M Camera Housing
The MOBOTIX S15M consists of a base plate for attaching the camera, a housing with
built-in lens, and a housing cover.
Externally-Accessible Connections on the S15M
The MOBOTIX S15M provides the following external connections that can be accessed
once the cover plugs are removed:
The external connections may only be used with the designated sealed MOBOTIX cables
(MX-OPT-CBL-LAN-1/2/5/10 Ethernet patch cable and MX-MX-CBL_MU_STR-5 MiniUSB
cable).
Pressure compen-
sations
Lens with dome
Base plate
R L
21
LEDs
MicroSD Card
Keys
Triple cable retainer
Bayonet catch
S15Mhousing cover
LED default settings:
1 Power (on), Error (ashes)
2 Recording (ashes)
MiniUSB
Ethernet patch cable
Cables with straight
plugs can be used for the
S15 on the camera only
