1.3.2 L12 Sensor Module
Item Number Part Name
3.1 1 Sensor module with axed washer
3.2 1 L12 lens (installed)
3.3 1 Dome (installed)
3.4 1 Cable retainer with bayonet catch (installed)
3.5 1 Sealing plug, blue, small (installed)
3.6 1 Nut (plastic)
Sensor module
including status LEDs
and microphone
3.1
3.4
3.5
3.2
3.6
3.3
