Delivered Parts and Dimensions
© MOBOTIX AG • Security-Vision-Systems • Made in Germany
www.mobotix.com • sales@mobotix.com
Item Number Part Name
1.1 1 S15D Core (base module with base plate)
1.2 1 Housing cover for S15D (installed)
1.3 1 Stainless steel flat-head Allen screw M4x8 (installed)
1.4 1 Washer (installed)
1.5 3 Sealing plug, blue, small (sensor modules, USB, inserted)
1.6 1 Sealing plug, blue, large (Ethernet patch cable, installed)
1.7 1 Cable retainer with bayonet catch (Ethernet patch cable,
installed)
1.8 1 Single wire plug, white (Ethernet installation cable, microphone,
speaker, MxBus; installed)
1.9 1 MicroSD card, 4GB (installed)
1.10 1 Rotary plug, SD card, blue (installed)
1.11 1 Ethernet patch cable, 50cm, with seal
Mounting Parts
Item Number Part Name
M.1 4 Stainless steel washers, diam. 4.3mm
M.2 4 6-mm screw anchors
M.3 4 Stainless steel wood screws 4x40mm with PZ 2 driver bit
M.4 2 Cable plug, 5–7mm, white (Ethernet installation cable)
M.5 1 Cable plug, 3–5mm, white (Ethernet installation cable)
M.6 1 Allen wrench 2.5mm
M.7 1 Lens wrench (lens, dome)
M.8 1 Module wrench (sensor module, glass/filter insert)
M.9 1 Cable tie (Ethernet installation cable, microphone, speaker,
MxBus)
M.10 1 Screwdriver (screw clamps)
