S15 Camera Manual: Product Overview
© MOBOTIX AG • Security-Vision-Systems • Made in Germany
www.mobotix.com • sales@mobotix.com
Dimensions S15M
Attaching the Camera Housing
The drilling templates
can be found at the
end of the manual
Always print or copy
drilling template in
their original size
115mm/4.53in
100mm/3.94in
M6
Diam. 5.5mm/
0.22in
130mm/5.12in
47.5mm/1.87in
100mm/3.94in
110mm/4.33in
8.5mm/0.33in
13.5mm/0.53in
M6 threaded holes
Slots
