25
1. Do not place the pressure cu over a jacket or sweater sleeve. Wrap
the pressure cu around the bare wrist with the monitor facing you.
Applying the Cuff
2. Wrap the cu snugly. Do not make
it too tight.
3. Fold the remaining part of the cu
back out of the way.
4. Leave approximately 0.4 inch
(10 mm) between the cu and the
bottom of your hand palm.
0.4inch(10mm)
5.3 ~ 7.7 inch (135 ~ 195 mm)
• Do not use this device if your wrist has any wound or injury.
• Do not wrap the cu around any body part other than your wrist.
2.
3. 4.
NOTE
To Next Page
