Ref.
Device Description
1
Control panel and LCD display
2
Bacteriological filter
3
Door
4
Waste water drainage quick coupling
5
Water drainage filter
6
Dust filter (S versions excluded)
7
Distilled water tank drainage quick coupling (SERVICE ONLY)
8
Distilled water top-up quick coupling (S versions excluded)
9
Drain tank
10
Filling tank
11
USB port
12
Power switch
Ref.
Description of electrical and hydraulic connections
13
Power cord connection
14
Network fuses
15
External filling electrical connection (S versions excluded)
16
Serial cable connection
17
Automatic filling connection (S versions excluded)
18
Direct drainage connection
19
Fastening slots for rear spacers
20
MODEL
21
Data plate SERIAL NUMBER LABEL
