Moduline HHT052E - General Recommendations and Technical Data

GENERAL RECOMMENDATIONS
AND TECHNICAL DATA
GB
Ed. 0314
8
GENERAL RECOMMENDATIONS FOR THE INSTALLER
• Installation, start-up and maintenance of the appliance should be
carried out by qualified engineers, licensed fitters or personnel
authorised by the manufacturer.
• Carefully read the recommendations in this instruction booklet, as they
provide important advice for safe installation, operation and
maintenance.
• Keep this booklet to hand in a safe place for future reference.
• This appliance should be used only for the purpose for which it has been
expressly designed, keeping it warm any other use should be considered
incorrect and therefore dangerous.
• After having unpacked the appliance, check that it is in perfect condition.
If in doubt, do not use the appliance and contact authorised personnel.
• Do not leave any packing material within reach of children, as it is a potential source of danger.
• Before connecting the appliance, make sure that the data on the rating plate (at the rear towards the bottom) correspond to the
mains supply data (electricity).
• In case of failure or malfunctioning, turn off the appliance immediately.
TECHNICAL DATA
Model (type)
Rated voltage
[Vac]
Total input
[kW]
Amps.
[A]
Cable according to IEC
-
60245
-
57
(H05RN-F or HO7RN-F). Minimum
cross section of connection cable
[mm2]
HHT
052E (
HHT
052E)
230
1,5 6,5
3 x 1
HHT
081E (
HHT
081E)
1 4,4
HHT
082E (
HHT
082E)
1,5 6,5
HHT
161E (
HHT
161E)
2 8,7
HHT
162E (
HHT
162E)
3 13,0
3 x 1,5
HHT
282E (
HHT
282E)
3 13,0
Model (type)
Operating
temperature
(°C)
Tray capacity:
distance [mm]
Tray max. height [mm]
Maximum total load
(product + trays)
h65
GN1/1) [kg]
Weight when
empty [kg]
HHT052E
(HHT052E)
30 ÷ 120
5 x GN 2/1 (70) 5 x 65 (h) 2 x 150 (h)
1 x 200 (h)
+ 2 x 65 (h)
36 + 15 51
10 x GN 1/1 (70) 10 x 65 (h) 4 x 150 (h)
2 x 200 (h)
+ 4 x 65 (h)
HHT
081E
(HHT081E)
8 x GN 1/1 (70) 8 x 65 (h) 3 x 150 (h)
2 x 200 (h)
+ 2 x 65 (h)
29 + 12 46
HHT082E
(HHT082E)
8 x GN 2/1 (70) 8 x 65 (h) 3 x 150 (h)
2 x 200 (h)
+ 2 x 65 (h)
58 + 24 62
16 x GN 1/1 (70) 16 x 65 (h) 6 x 150 (h)
4 x 200 (h)
+ 4 x 65 (h)
HHT
161E
(HHT161E)
16 x GN 1/1 (70) 16 x 65 (h) 6 x 150 (h)
4 x 200 (h)
+ 4 x 65 (h)
58 + 24 88
HHT162E
(HHT162E)
16 x GN 2/1 (70) 16 x 65 (h) 6 x 150 (h)
4 x 200 (h)
+ 4 x 65 (h)
115 + 48 106
32 x GN 1/1 (70) 32 x 65 (h) 12 x 150 (h)
8 x 200 (h)
+ 8 x 65 (h)
HHT282E
(HHT282E)
8 x GN 2/1 (70)
+
8 x GN 2/1 (70)
8 x 65 (h)
+
8 x 65 (h)
3 x 150 (h)
+
3 x 150 (h)
2 x 200 (h)
+ 2 x 65 (h)
+
2 x 200 (h)
+ 2 x 65 (h)
115 + 48 111
Example of rating plate
