Modulus Arms Jig Contents
The Modulus Arms Universal AR-15 80% Lower Receiver Jig contains the following parts:
1. 1x Template
2. 2x Side Plate
3. 1x Drill Guide
4. 1x Front Support
5. 1x Rear Support
6. 1x Buffer Support
7. 1x Depth Gauge
8. 14x Screws [8-32 x ½”]
9. 2x Side Plate Screw [8-32 x 1.5”]
10. 1x Rear Take Down Bolt [1/4-20 x 2.25”]
11. 1x Flat Washer [1/4”}
12. 1x Rear Take Down Nut [1/4”}
Figure 1: Jig Contents
2
9
10, 11, 12
8
3
6
7
1
5
4
