modway EEI-2547 - Step 1: Attach Front Legs to Seat; Leg Attachment Procedure; Step 2: Connect Chair Seat to Chair Back; Seat to Back Connection

EEI-2547
A×4 B×4 C×4
STEP1:
STEP2:
A×4 B×4 C×4
Legs Package
+
Hardware Package
Please open the Velcro on the bottom of Chair Seat (2).
Insert 1 piece of Front Leg (3) into the bottom of Chair Seat (2) as shown.
Attach by 2 pieces of
Bolt (A), 2 pieces of Spring Washer (B), and 2 pieces of Flat Washer (C) as
shown.
Repeat the same steps for another Front Leg (3).
Do not fully tighten Bolts (A) for either leg.
Please put Chair Back (1) upside down on a carpeted or padded area.
Then attach Chair Seat (2) to Chair Back (1) by using 2 pieces of Bolt (A), 2 pieces of Spring
Washer (B), and 2 pieces of Flat Washer (C) for each corner as shown.
Do not fully tighten all Bolts (A).
D×1
D×1
