modway EEI-6156 - What You Need

PAGE 2 OF 13
1
2
3
4
5
6
7
7
8
9
10
10
LC16A1
12
12
x 2
13
13
14
14
15
15
16
17
18
19
18
18
19
11
11
11
Furniture components:
2 x1Bottom Board
3 x1Side Board Left
4 x1Side Board Right
1 x1Top Board
6 x1Center Board Right
7 x2Adjustable Shelf
8 x1Fixed Shelf
5 x1Center Board Left
10 x2Support Leg
11 x3Back Board
12 x2Top Board (Cubby)
9 x2Assembly Leg
14 x2Middle Board
15 x2Cubby Divider
16 x1Door Frame - Left
13 x2Side Board (Cubby)
18 x4Stemware Holder 1
19 x4Stemware Holder 1
LC16A1 x2Center Leg
17 x1Door Frame - Right
Provided hardware:
PM2
x2Mounting Plate
HS35A
x4
Q
x12
R
x2Stopper
What you need:
Phillips Head Screwdriver
Phillips
Let’s get started!
Approx. 70 minutes
assembly time
2 people recommended
for assembly
Care instructions are
listed in the last step
of this manual
Read through all of
the instructions
before starting
Make sure you have all
parts and components
before discarding any
packing materials
Hinge
E
F
J
K
L
M
P
x24
x24
x2
x48
x16
x16
x4
A
x22Cam Bolt Ø6 x 35 mm Wedge
B
x22Cam Lock Ø15 mm Screw M 3.5 x 15.5 mm
D
x10Screw M 7 x 50 mm
C
x52Wood Dowel Ø8 x 30 mm
Allen Key
Wood Dowel Ø6 x 30 mm
G
x4JCN Nut
Screw M 6.4 x 35 mm
Screw M 8 x 39 mm
Screw M 6 x 25 mm
H
x32Screw M 4.5 x 12.5 mm
I
x8Screw Cap Ø15 mm
N
O
x8Shelf Pin
x4
Floor Protector
25 x 15 x 2 mm
Floor Protector
15 x 15 x 2 mm
