modway EEI-6156 - Page 6

PAGE 6 OF 13
C OMPO NENTS
x1
Bottom Board
2
x3
Back Board
11
x8
Screw M 7 x 50 mm
D
x1
Allen Key
E
HARDWARE
Step 7
x10
Cam Bolt Ø6 x 35 mm
A
x8
Screw M 4.5 x 12.5 mm
H
x2
Mounting Plate
HARDWARE
Step 8
D
D
E
E
2
11
11
11
Laminated
Laminated
Laminated
PM2
A
PM2
PM2
H
H
2
A
