PAGE 8 OF 13
x12
Wood Dowel Ø8 x 30 mm
C
Step 11
HARDWARE
x10
Cam Lock Ø15 mm
B
x4
Floor Protector 25x15x2 mm
O
Step 12
HARDWARE
x2
Center Leg
Step 13
C OMPO NENTS
C
B
B
O
O
2
LC16A1
LC16A1
LC16A1
