PAGE 2 OF 8
Provided hardware:
Furniture components:
E
F
x2
x4
A
x4Cam Bolt Ø6 x 35 mm
B
x4Cam Lock Ø15 mm
D
x4Screw M 7 x 50 mm
C
x8Wood Dowel Ø8 x 30 mm
Allen Key
Shelf Pin
G
x24Screw M 4.5 x 12.5 mm
Missing parts or hardware? Need assistance?
Contact us before returning your item. We're here to help!
609.256.9000 • cs@modway.com
H
x4Screw Cap Ø15 mm
Only use hand tools to assemble this item. Do not use power tools.
Do not tighten bolts or screws completely until all hardware is lined up
and inserted into the holes.
Do not over-tighten screws and bolts to avoid stripping the hardware
or cracking the item.
you’re assembling the product.
Keep all components and packaging out of reach of children or animals
Approx. 60 minutes
assembly time
2 people recommended
for assembly
Care instructions are
listed in the last step
of this manual
Read through all of
the instructions
before starting
Make sure you have all
parts and components
before discarding any
packing materials
Let’s get started!
What you need:
Phillips Head Screwdriver
Phillips
x1
x2
x4
1 x1
2 x1Bottom Board
Top Board
3 x1Center Board Left
5
7
8
x14 Center Board Right
Adjustable Shelf
x26 Door Sliding
Back Board
Pilar
x4LegLB18C1
x2Center LegLC16A1
I
x8Wood Dowel Ø6 x 30 mm
PM3
x4Mounting Plate
PM2
x2Mounting Plate
1
2
3
4
5
6
6
7
7
8
8
LB18C1
LB18C1
LC16A1
