modway EEI-6795 - Step 2: Secure Center Boards; Connect Center Boards with Cam Locks; Apply Screw Caps; Step 3: Attach Pillars

PAGE 4 OF 8
Step 3
Step 2
x4
Pilar
8
C OMPO NENTS
B
H
x4
Cam Lock Ø15 mm
B
x4
Screw Cap Ø15 mm
H
HARDWARE
C OMPO NENTS
x1
Center Board Left
3
x1
Top Board
1
x1
Center Board Right
4
B
H
1
3
4
8
8
8
8
8 8


