modway MOD-6213 - Hardware List; Bed Frame Assembly Instructions; Step 1: Initial Frame Assembly; Step 2: Attaching Side Rails

MOD-6213
HARDWARE BED FRAME
Customer Service 609-256-9000 | www.modway.com
02 of 06
1
JCBC BOLT M6 x 100mm
3 PCS
2
JCBC BOLT M6 x 50mm
16 PCS
3
JCBC BOLT M6 x 40mm
18 PCS
4
JCBC BOLT M6 x 20mm
8 PCS
8
M6 SPRING WASHER
24 PCS
9
M6 FLAT WASHER
24 PCS
10
PH SCREW M4 x 32mm
16 PCS
11
M4 ALLEN KEY
1 PC
STEP 1
5
JCBC BOLT M6 x 15mm
4 PCS
6
JCBB BOLT M8 x 50mm
8 PCS
7
BARREL NUT
3 PCS
12
M5 ALLEN KEY
1 PC
13
L BRACKET
2 PCS
14
ADJUSTABLE FOOT
3 PCS
STEP 2
10
10
F
G
H
F
G
I
H
12
6
I
